Maurice J Slot

US Patent:

20090114391, May 7, 2009

Filed:

Nov 2, 2007

Appl. No.:

11/934513

Inventors:

Maurice Slot - Nichols Hills OK, US
Richard R. Watson - Missouri City TX, US

Assignee:

NATIONAL COUPLING COMPANY, INC. - STAFFORD TX

International Classification:

E21B 43/16

US Classification:

1663051

Abstract:

A control program for a positive displacement metering system measures the time required for the travel of a free piston in a cylinder of known volume to determine an average flow rate during a full stroke of the piston. The system may also measure and record the inlet and outlet pressures or the differential pressure between the fluid inlet and outlet. The control program positions a four-way valve which may function as an adjustable metering orifice in response to the measured average flow rate and/or changes in the inlet and outlet pressures to achieve the desired flow rate. At the end of each stroke, the four-way valve is repositioned to reverse fluid flow through the metering cylinder. The system may revise the valve position settings for both forward and reverse strokes based on the measured time required for a full stroke at a certain valve position. In this way, the system automatically and iteratively compensates for changes in fluid properties and fluid pressure. A cleaning cycle which progressively opens the valve stepwise and may culminate in full open valve travel in both fluid flow directions is provided in the event of an obstruction of the valve orifice.

US Patent:

20130180719, Jul 18, 2013

Filed:

Jan 2, 2013

Appl. No.:

13/732999

Inventors:

Maurice Slot - Nichols Hills OK, US
Richard R. Watson - Missouri City TX, US

International Classification:

E21B 37/06

US Classification:

1663051

Abstract:

A control program for a positive displacement metering system measures the time required for the travel of a free piston in a cylinder of known volume to determine an average flow rate during a full stroke of the piston. The system may also measure and record the inlet and outlet pressures or the differential pressure between the fluid inlet and outlet. The control program positions a four-way valve which may function as an adjustable metering orifice in response to the measured average flow rate and/or changes in the inlet and outlet pressures to achieve the desired flow rate. At the end of each stroke, the four-way valve is repositioned to reverse fluid flow through the metering cylinder. The system may revise the valve position settings for both forward and reverse strokes based on the measured time required for a full stroke at a certain valve position. In this way, the system automatically and iteratively compensates for changes in fluid properties and fluid pressure. A cleaning cycle which progressively opens the valve stepwise and may culminate in full open valve travel in both fluid flow directions is provided in the event of an obstruction of the valve orifice.

US Patent:

20150308234, Oct 29, 2015

Filed:

Jul 2, 2015

Appl. No.:

14/790429

Inventors:

- Stafford TX, US
Maurice Slot - Nichols Hills OK, US
Richard R. Watson - Missouri City TX, US

International Classification:

E21B 37/06
G05D 7/06
G05B 15/02

Abstract:

A control program for a positive displacement metering system measures the time required for the travel of a free piston in a cylinder of known volume to determine an average flow rate during a full stroke of the piston. The system may also measure and record the inlet and outlet pressures or the differential pressure between the fluid inlet and outlet. The control program positions a four-way valve which may function as an adjustable metering orifice in response to the measured average flow rate and/or changes in the inlet and outlet pressures to achieve the desired flow rate. At the end of each stroke, the four-way valve is repositioned to reverse fluid flow through the metering cylinder. The system may revise the valve position settings for both forward and reverse strokes based on the measured time required for a full stroke at a certain valve position. In this way, the system automatically and iteratively compensates for changes in fluid properties and fluid pressure. A cleaning cycle which progressively opens the valve stepwise and may culminate in full open valve travel in both fluid flow directions is provided in the event of an obstruction of the valve orifice.
