Michael A Furlan

US Patent:

57366993, Apr 7, 1998

Filed:

May 3, 1996

Appl. No.:

8/642366

Inventors:

Michael R. Furlan - Des Plaines IL
George D. Georgacakis - Stokie IL
Norman A. Schutzkus - S. Elgin IL

Assignee:

Eaton Corporation - Cleveland OH

International Classification:

H01H 4310

US Classification:

200 38R

Abstract:

The present invention provides an electro-mechanical programmer/timer having a plurality of switches actuated by a rotating program cam with each of the switches tracking a separate cam track on the cam. The program cam is indexed by a pawl which engages ratchet teeth on the program cam. The pawl is oscillated by engagement with a sub-interval cam driven by a motor drive. At least one of the switches following the program cam is a single-pole double-throw switch with the center blade thereof actuated by a cam follower lever operated by a separate track on the sub-interval cam.
