Michael A Grudek

US Patent:

20120175388, Jul 12, 2012

Filed:

Jan 12, 2011

Appl. No.:

13/005345

Inventors:

Michael A. Grudek - Encinitas CA, US

International Classification:

B62D 43/00

US Classification:

224 4212

Abstract:

A spare tire carrier that preserves the vehicle approach angle. The carrier comprises a hitch anchor configured to be mounted on a vehicle towing hitch; a fork having tines affixed to the back end of the hitch anchor by means of a hinge; a sleeve slidingly mounted on the fork's handle; a lower shoulder bar essentially perpendicularly mounted onto the sleeve; an upper shoulder bar slidingly mounted on the lower shoulder bar and a rim holder affixed to the upper shoulder bar. The device is constructed of telescoping bars that can be slidingly adjusted and kept in place by pins. This design allows the shape of the device to be modified and to accommodate a diversity of tire sizes. This invention can also be used as a jack by positioning the rim holder on the ground as a fulcrum and using the device as a lever to lift a car.
