Michael W Karpa

US Patent:

D691497, Oct 15, 2013

Filed:

Jun 12, 2012

Appl. No.:

29/424458

Inventors:

George Jambor - Richmond IL, US
Scott Stilin - Richmond IL, US
Ryan Affara - Richmond IL, US
Arthur Volbrecht - Richmond IL, US
Michael Karpa - Richmond IL, US

Assignee:

Watlow Electric Manufacturing Company - St. Louis MO

International Classification:

1004

US Classification:

D10 60

US Patent:

20130329767, Dec 12, 2013

Filed:

Jun 12, 2013

Appl. No.:

13/916230

Inventors:

Scott Stilin - Richmond IL, US
Ryan Affara - Richmond IL, US
Arthur Volbrecht - Richmond IL, US
Michael Karpa - Richmond IL, US

Assignee:

Watlow Electric Manufacturing Company - St. Louis MO

International Classification:

G01K 7/22

US Classification:

374185

Abstract:

A temperature sensor assembly is provided that includes a handle defining an internal cavity, and a probe secured to the handle and extending distally therefrom. The probe includes a sheath, a thermistor disposed within the sheath and defining a pair of wires and a bead formed at a distal end portion of the pair of wires. An electrical noise suppression device is disposed within the internal cavity of the handle and is electrically connected to the pair of thermistor wires. A set of lead wires is secured to a proximal end portion of the handle and are electrically connected to the electrical noise suppression device. An adhesive lined heat shrink tubing extends from around the bead of the thermistor, around the pair of thermistor wires, around the electrical noise suppression device, and to around at least a portion of the lead wires.
