Us Patents

Test Structure Design For Reliability Test
view source
US Patent:

7119571, Oct 10, 2006
Filed:

Nov 24, 2004
Appl. No.:

10/997267
Inventors:

Naomi Yoshida - Sunnyvale CA, US
Toshiyuki Nagata - Los Gatos CA, US
Assignee:

Applied Materials, Inc. - Santa Clara CA
International Classification:

G01R 31/26
US Classification:

324765
Abstract:

A flexible semiconductor test structure that may be incorporated into a semiconductor device is provided. The test structure may include a plurality of test pads designed to physically stress conductive lines to which they are attached during thermal cycling. By utilizing test pads with different dimensions (lengths and/or widths), the effects of thermal stress generated by a plurality of conductive lines having corresponding different dimensions may be simulated.

Test Structure Design For Reliability Test
view source
US Patent:

7365529, Apr 29, 2008
Filed:

Aug 18, 2006
Appl. No.:

11/465646
Inventors:

Naomi Yoshida - Sunnyvale CA, US
Toshiyuki Nagata - Los Gatos CA, US
Assignee:

Applied Materials, Inc. - Santa Clara CA
International Classification:

G01R 31/28
US Classification:

3241581
Abstract:

A flexible semiconductor test structure that may be incorporated into a semiconductor device is provided. The test structure may include a plurality of test pads designed to physically stress conductive lines to which they are attached during thermal cycling. By utilizing test pads with different dimensions (lengths and/or widths), the effects of thermal stress generated by a plurality of conductive lines having corresponding different dimensions may be simulated.

Oxygen Free Deposition Of Platinum Group Metal Films
view source
US Patent:

20230025937, Jan 26, 2023
Filed:

Sep 29, 2022
Appl. No.:

17/955996
Inventors:

- Santa Clara CA, US
Wei V. Tang - Santa Clara CA, US
Seshadri Ganguli - Sunnyvale CA, US
Sang Ho Yu - Cupertino CA, US
Feng Q. Liu - San Jose CA, US
Jeffrey W. Anthis - San Jose CA, US
David Thompson - San Jose CA, US
Jacqueline S. Wrench - San Jose CA, US
Naomi Yoshida - Sunnyvale CA, US
Assignee:

Applied Materials, Inc. - Santa Clara CA
International Classification:

H01L 21/285
C23C 16/455
C23C 16/18
H01L 23/532
C23C 16/04
Abstract:

Methods of depositing platinum group metal films of high purity, low resistivity, and good conformality are described. A platinum group metal film is formed in the absence of an oxidant. The platinum group metal film is selectively deposited on a conductive substrate at a temperature less than 200 C. by using an organic platinum group metal precursor.

Fluorine-Free Tungsten Ald And Tungsten Selective Cvd For Dielectrics
view source
US Patent:

20210384035, Dec 9, 2021
Filed:

Apr 8, 2021
Appl. No.:

17/225667
Inventors:

- Santa Clara CA, US
Shih Chung Chen - Cupertino CA, US
Kedi Wu - Fremont CA, US
Ashley Lin - New Taipei, TW
Chi-Chou Lin - San Jose CA, US
Yi Xu - San Jose CA, US
Yu Lei - Belmont CA, US
Mandyam Sriram - San Jose CA, US
Wen Ting Chen - San Jose CA, US
Srinivas Gandikota - Santa Clara CA, US
Chenfei Shen - San Jose CA, US
Naomi Yoshida - Sunnyvale CA, US
He Ren - San Jose CA, US
Assignee:

Applied Materials, Inc. - Santa Clara CA
International Classification:

H01L 21/285
H01L 21/02
C23C 16/14
C23C 16/02
Abstract:

Methods of forming metallic tungsten films selectively on a conductive surface relative to a dielectric surface are described. A substrate is exposed to a first process condition to deposit a fluorine-free metallic tungsten film. The fluorine-free metallic tungsten film is exposed to a second process condition to deposit a tungsten film on the fluorine-free metallic tungsten film.

Fluorine-Free Tungsten Ald For Dielectric Selectivity Improvement
view source
US Patent:

20210384036, Dec 9, 2021
Filed:

Jun 4, 2021
Appl. No.:

17/339454
Inventors:

- Santa Clara CA, US
Chi-Chou Lin - San Jose CA, US
Kedi Wu - Fremont CA, US
Wen Ting Chen - San Jose CA, US
Shih Chung Chen - Cupertino CA, US
Srinivas Gandikota - Santa Clara CA, US
Mandyam Sriram - San Jose CA, US
Chenfei Shen - San Jose CA, US
Naomi Yoshida - Sunnyvale CA, US
He Ren - San Jose CA, US
Assignee:

Applied Materials, Inc. - Santa Clara CA
International Classification:

H01L 21/285
C23C 16/455
C23C 16/14
C23C 16/04
Abstract:

Methods of forming metallic tungsten films selectively on a conductive surface relative to a dielectric surface are described. A substrate is exposed to a first process condition to deposit a tungsten-containing film that is substrate free of tungsten metal. The tungsten-containing film is then converted to a metallic tungsten film by exposure to a second process condition.

Method Of Dielectric Material Fill And Treatment
view source
US Patent:

20210317580, Oct 14, 2021
Filed:

Apr 14, 2020
Appl. No.:

16/848784
Inventors:

- Santa Clara CA, US
He REN - San Jose CA, US
Naomi YOSHIDA - Sunnyvale CA, US
Nikolaos BEKIARIS - Campbell CA, US
Mehul NAIK - San Jose CA, US
Martin Jay SEAMONS - San Jose CA, US
Jingmei LIANG - Santa Clara CA, US
Mei-Yee SHEK - Santa Clara CA, US
International Classification:

C23C 16/56
H01L 21/768
Abstract:

Embodiments herein provide for oxygen based treatment of low-k dielectric layers deposited using a flowable chemical vapor deposition (FCVD) process. Oxygen based treatment of the FCVD deposited low-k dielectric layers desirably increases the Ebd to capacitance and reliability of the devices while removing voids. Embodiments include methods and apparatus for making a semiconductor device including: etching a metal layer disposed atop a substrate to form one or more metal lines having a top surface, a first side, and a second side; depositing a passivation layer atop the top surface, the first side, and the second side under conditions sufficient to reduce or eliminate oxygen contact with the one or more metal lines; depositing a flowable layer of low-k dielectric material atop the passivation layer in a thickness sufficient to cover the one or more metal lines; and contacting the flowable layer of low-k dielectric material with oxygen under conditions sufficient to anneal and increase a density of the low-k dielectric material

Horizontal Gate All Around Device Nanowire Air Gap Spacer Formation
view source
US Patent:

20200411656, Dec 31, 2020
Filed:

Sep 14, 2020
Appl. No.:

17/020372
Inventors:

- Santa Clara CA, US
Nam Sung KIM - Sunnyvale CA, US
Bingxi Sun WOOD - Cupertino CA, US
Naomi YOSHIDA - Sunnyvale CA, US
Sheng-Chin KUNG - Milpitas CA, US
Miao JIN - San Jose CA, US
International Classification:

H01L 29/423
H01L 29/78
H01L 21/02
H01L 29/775
H01L 29/786
H01L 29/06
H01L 29/66
Abstract:

Embodiments provide apparatuses and methods for forming nanowire structures with desired materials horizontal gate-all-around (hGAA) structures field effect transistor (FET) for semiconductor chips. In one embodiments, a nanowire structure is provided and includes a stack containing repeating pairs of a first layer and a second layer and having a first side and a second side opposite from the first side, a gate structure surrounding the stack, a source layer adjacent to the first side, and a drain layer adjacent to the second side. The stack also contains one or more gaps disposed between the source layer and the second layer and having a dielectric constant value of about 1 and one or more gaps disposed between the drain layer and the second layer and having a dielectric constant value of about 1.
