Norman V Kurlander

US Patent:

55704859, Nov 5, 1996

Filed:

Dec 12, 1995

Appl. No.:

8/571245

Inventors:

Norman V. Kurlander - East Amherst NY
Gregory A. Fry - Lockport NY
Dennis J. Pomietlasz - Barker NY

Assignee:

NK Medical Products, Inc. - Buffalo NY

International Classification:

A47D 701
A61G 700

US Classification:

5617

Abstract:

A bed assembly (10) having a generally rectangular frame (22) and a mattress support (62, 64, 66, 68), the mattress support including a hinged head section (14) movable between raised and lowered positions, and an extender (76) supported by the hinged head section for extensible and retractable movement, the extender bridging the space between a headboard assembly (18) and the hinged head section when the hinged head section is in a raised position. An extender operating assembly (112) is provided for causing the extender to be extended towards the headboard assembly when the hinged head section is raised and for causing the extender to retract when the hinged head section is lowered. The extender operating assembly includes a sheave assembly preferably in the form of a pulley block (114) carried by the hinged head section, and a cord (116) having spaced apart ends and an intermediate section, the intermediate section (116. 1) of the cord passing over the pulley block, one end (116.
