Patrick J O'Connell

US Patent:

7059365, Jun 13, 2006

Filed:

Oct 10, 2003

Appl. No.:

10/683745

Inventors:

Patrick R. O'Connell - Rochester Hills MI, US

Assignee:

Shelby Enterprises, Inc. - Romeo MI

International Classification:

B65B 1/04

US Classification:

141 46, 141286, 220 862

Abstract:

A fuel tank filler assembly includes a filler neck configured to receive a fuel supply nozzle. The filler neck includes a one-piece seamless funnel member having a tubular body configured to swirl supplied fuel and reduce vapor escape. The tubular body includes integrally formed threads for receiving a gas cap. The funnel member defines in off-set axial relation a relatively large inlet opening adapted for attachment to a receptor for the nozzle and a relatively small necked down outlet opening adapted for attachment to the inlet of a filler tube. The filler tube is in communication with the fuel tank. A method for manufacturing the fuel tank filler neck is also disclosed.

US Patent:

7343942, Mar 18, 2008

Filed:

Jul 8, 2003

Appl. No.:

10/615485

Inventors:

Patrick R. O'Connell - Rochester Hills MI, US

Assignee:

Shelby Enterprises, Inc. - Romeo MI

International Classification:

B65B 1/04

US Classification:

141 46, 141286, 220 862

Abstract:

A method of forming a gas tank filler neck includes configuring at least a portion of a seamless tubular member to induce a swirl to passing fuel for venting vapors from the gas tank during fuel filling. The configuration may include deep drawing a seamless funnel member, forming a relatively large inlet at one end thereof, and forming a relatively small outlet at the opposite end thereof, the inlet having an axis offset from the axis of the outlet. A filler neck includes a seamless funnel member defining a relatively large inlet opening and relatively small outlet opening, the position of the inlet opening relative the outlet opening inducing a swirl to the fuel being supplied.

US Patent:

20020083997, Jul 4, 2002

Filed:

Nov 30, 2001

Appl. No.:

09/998113

Inventors:

Patrick O'Connell - Rochester Hills MI, US

International Classification:

B65B031/00

US Classification:

141/046000, 220/086200

Abstract:

A fuel tank filler neck is provided to reduce the escape of gasoline vapor from an automobile fuel tank system and is leak tight. The filler neck is configured to receive a fuel supply nozzle. The filler neck includes a one-piece seamless funnel member having a tubular body and an elongated tubular member. The funnel member defines in off-set axial relation a relatively large inlet opening adapted for attachment to a receptor for the nozzle and a relatively small necked down outlet opening adapted for attachment to the inlet of an elongated tubular member. The tubular member is adapted to be in communication with the fuel tank. A method for manufacturing the fuel tank filler neck is also disclosed.

US Patent:

20080128415, Jun 5, 2008

Filed:

Feb 12, 2008

Appl. No.:

12/029855

Inventors:

Patrick R. O'Connell - Rochester Hills MI, US

Assignee:

Shelby Enterprises, Inc. - Romeo MI

International Classification:

B60K 15/04
B65B 3/18

US Classification:

220 862, 141 46, 141286

Abstract:

A filler neck assembly includes a funnel member having a tubular body defining a transition portion between an inlet opening and an outlet opening and a nozzle receptor disposed within the tubular body. The nozzle receptor positions a nozzle relative to the transition portion to create a suctioning effect that prevents fuel vapors from escaping into the atmosphere during fueling.

US Patent:

63308932, Dec 18, 2001

Filed:

Dec 3, 1999

Appl. No.:

9/454103

Inventors:

Patrick R. O'Connell - Rochester Hills MI

Assignee:

Shelby Enterprises, Inc. - Romeo MI

International Classification:

B65B 104

US Classification:

141 46

Abstract:

A fuel tank filler neck is provided to reduce the escape of gasoline vapor from an automobile fuel tank system and is leak tight. The filler neck is configured to receive a fuel supply nozzle. The filler neck includes a one-piece seamless funnel member having a tubular body and an elongated tubular member. The funnel member defines in off-set axial relation a relatively large inlet opening adapted for attachment to a receptor for the nozzle and a relatively small necked down outlet opening adapted for attachment to the inlet of an elongated tubular member. The tubular member is adapted to be in communication with the fuel tank. A method for manufacturing the fuel tank filler neck is also disclosed.

US Patent:

20220317444, Oct 6, 2022

Filed:

Jun 17, 2022

Appl. No.:

17/842868

Inventors:

- Peachtree City GA, US
PATRICK O'CONNELL - NOVI MI, US

International Classification:

G02B 27/01
G02B 27/28

Abstract:

A head up display arrangement for a motor vehicle includes a head up display module having a picture generation unit emitting a light field. A polarizing device is rotatable between at least a first rotational position and a second rotational position. The polarizing device receives the light field from the picture generation unit and emits the light field regardless of whether the polarizing device is in the first rotational position or the second rotational position. More of the light is emitted by the polarizer in a P-polarization state in the second rotational position than in the first rotational position. A windshield reflects the light field from the polarizing device such that the reflected light field is visible to a human driver of the motor vehicle as a virtual image.

US Patent:

20210048670, Feb 18, 2021

Filed:

Aug 10, 2020

Appl. No.:

16/989331

Inventors:

- Peachtree City GA, US
PATRICK O'CONNELL - NOVI MI, US

International Classification:

G02B 27/01
B60R 11/02

Abstract:

A head up display arrangement for a motor vehicle includes a picture generation unit producing a light field. A digital micromirror device is positioned to reflect the light field. The digital micromirror device includes an array of mirrors each having an individually adjustable orientation. An electronic processor is communicatively coupled to the digital micromirror device and individually adjusts the orientation of each mirror such that the light field reflected by the digital micromirror device is visible to the driver as a virtual image.

US Patent:

20200101898, Apr 2, 2020

Filed:

Oct 1, 2019

Appl. No.:

16/589177

Inventors:

- Peachtree City GA, US
PATRICK O'CONNELL - NOVI MI, US

International Classification:

B60R 1/00
H04N 5/225
G06K 9/00
B60R 1/12
B60K 35/00
B60Q 9/00

Abstract:

A head up display arrangement is for a motor vehicle having a human driver. A camera is positioned and configured to capture images of an object being towed by the vehicle. A head up display module produces virtual images that are visible to the driver. The head up display module is operable in a conventional mode in which the virtual images are independent of the images captured by the camera, and in a tow mode in which the virtual images are dependent upon the images captured by the camera.
