Paul Q Yuan

US Patent:

8152570, Apr 10, 2012

Filed:

Aug 18, 2011

Appl. No.:

13/213080

Inventors:

Min Chul Kim - Santa Clara CA, US
Paul Yuan - San Jose CA, US

Assignee:

Apple Inc. - Cupertino CA

International Classification:

H01R 13/64

US Classification:

439680

Abstract:

Circuits, methods, and apparatus that may provide protection from exposed wires or terminals when a power plug is damaged or destroyed. One example may provide a plug having an inner cover that shields power carrying wires or terminals when an outer shell is damaged or destroyed. The inner cover may include openings to receive conductors, where the openings may lead to terminals or wires that connect to plug prongs. The received conductors may attach directly or indirectly to an outer shell, and further to a power cord, circuitry, or other electronic components. When the outer shell is damaged or destroyed, the conductors may pull out of the openings in the inner cover, thus disconnecting from the wires or terminals. The wires or terminals may thus remain protected by the inner shell, avoiding exposure to contact by users or inadvertent conductors.

US Patent:

8327536, Dec 11, 2012

Filed:

Feb 23, 2011

Appl. No.:

13/033562

Inventors:

Min Chul Kim - Santa Clara CA, US
Paul Yuan - San Jose CA, US
Josh Pong - San Jose CA, US
Joseph Tang - Cupertino CA, US

Assignee:

Apple Inc. - Cupertino CA

International Classification:

H01R 43/02

US Classification:

29861, 29857, 29860, 43960741

Abstract:

High speed connector inserts and cables having improved heat conduction, high strength, and may be manufactured in a reliable manner. One example may provide a connector insert having several paths by which heat may be removed from circuitry in the cable insert. In one example, heat may be removed from one or more circuits by forming a thermal path between a circuit and a shield of the connector insert. Another path may include one or more pads on a side of an integrated circuit board that are soldered directly to the shield. A braiding surrounding a cable may be soldered or otherwise thermally connected to the shield. Another example may provide a cable having a braiding that includes one or more types of fibers, such as aramid fibers. Another example may provide for increased manufacturability by using a wire comb and a solder bar.

US Patent:

20120152613, Jun 21, 2012

Filed:

Feb 24, 2012

Appl. No.:

13/404949

Inventors:

Min Chul Kim - Santa Clara CA, US
Paul Yuan - San Jose CA, US
Josh Pong - San Jose CA, US
Joseph Tang - Cupertino CA, US

Assignee:

Apple Inc. - Cupertino CA

International Classification:

H02G 15/08
H01R 43/00

US Classification:

174 88 C, 29857

Abstract:

High speed connector inserts and cables having improved heat conduction, high strength, and may be manufactured in a reliable manner. One example may provide a connector insert having several paths by which heat may be removed from circuitry in the cable insert. In one example, heat may be removed from one or more circuits by forming a thermal path between a circuit and a shield of the connector insert. Another path may include one or more pads on a side of an integrated circuit board that are soldered directly to the shield. A braiding surrounding a cable may be soldered or otherwise thermally connected to the shield. Another example may provide a cable having a braiding that includes one or more types of fibers, such as aramid fibers. Another example may provide for increased manufacturability by using a wire comb and a solder bar.

US Patent:

20130210272, Aug 15, 2013

Filed:

Feb 9, 2012

Appl. No.:

13/370279

Inventors:

Paul Yuan - San Jose CA, US
Min Chul Kim - Santa Clara CA, US

Assignee:

Apple Inc. - Cupertino CA

International Classification:

H01R 9/05

US Classification:

439581

Abstract:

Structures and methods that simplify the assembly of connector inserts. One example may provide a connector insert having a termination block that is arranged to receive an end of a cable. The termination block may provide a first number of conductors in a first row and a second number of conductors in a second row. The termination block may be stepped such that the first number of conductors emerge from the termination block at a different position along their lengths than the second number of conductors. The first number of conductors may then attach to a first side of a printed circuit board or other connector portion, while the second number of conductors may then attach to a second side of the printed circuit board or other connector portion.

US Patent:

8011975, Sep 6, 2011

Filed:

Oct 29, 2010

Appl. No.:

12/916480

Inventors:

Min Chul Kim - Santa Clara CA, US
Paul Yuan - San Jose CA, US

Assignee:

Apple Inc. - Cupertino CA

International Classification:

H01R 13/64

US Classification:

439680, 439651, 439934

Abstract:

Circuits, methods, and apparatus that may provide protection from exposed wires or terminals when a power plug is damaged or destroyed. One example may provide a plug having an inner cover that shields power carrying wires or terminals when an outer shell is damaged or destroyed. The inner cover may include openings to receive conductors, where the openings may lead to terminals or wires that connect to plug prongs. The received conductors may attach directly or indirectly to an outer shell, and further to a power cord, circuitry, or other electronic components. When the outer shell is damaged or destroyed, the conductors may pull out of the openings in the inner cover, thus disconnecting from the wires or terminals. The wires or terminals may thus remain protected by the inner shell, avoiding exposure to contact by users or inadvertent conductors.

US Patent:

20180074988, Mar 15, 2018

Filed:

Sep 14, 2017

Appl. No.:

15/704597

Inventors:

- Cupertino CA, US
Aditya Rao - San Francisco CA, US
Bo Feng - Changzhou, CN
David S. Kumka - San Francisco CA, US
Joseph I. Briskey - Aptos CA, US
Min Chul Kim - San Jose CA, US
Paul Z. Yuan - San Jose CA, US
Yufan Liao - Cupertino CA, US
George Tziviskos - San Jose CA, US
Charles A. Schwalbach - Menlo Park CA, US
Eric H. Wong - San Francisco CA, US
David B. Kosecoff - San Francisco CA, US
Steven C. Michalske - Sunnyvale CA, US
Ariadne G. Smith - Cupertino CA, US

International Classification:

G06F 13/40
H01R 13/66
G06F 13/38
G06F 13/42
G11B 33/12
H01R 13/02
H01B 9/02
H01R 13/631

Abstract:

Systems for presenting electrically supported devices and methods for assembling the same are provided.

US Patent:

20170133798, May 11, 2017

Filed:

Jul 4, 2016

Appl. No.:

15/201580

Inventors:

- Cupertino CA, US
Paul Yuan - San Jose CA, US
Joshua J. Pong - San Jose CA, US
Joseph Tang - Pleasanton CA, US

Assignee:

Apple Inc. - Cupertino CA

International Classification:

H01R 13/6592
H01R 12/53
H02G 15/08
H01R 43/02
H01R 43/048
H01R 4/02
H01R 13/6463

Abstract:

High speed connector inserts and cables having improved heat conduction, high strength, and may be manufactured in a reliable manner. One example may provide a connector insert having several paths by which heat may be removed from circuitry in the cable insert. In one example, heat may be removed from one or more circuits by forming a thermal path between a circuit and a shield of the connector insert. Another path may include one or more pads on a side of an integrated circuit board that are soldered directly to the shield. A braiding surrounding a cable may be soldered or otherwise thermally connected to the shield. Another example may provide a cable having a braiding that includes one or more types of fibers, such as aramid fibers. Another example may provide for increased manufacturability by using a wire comb and a solder bar.

US Patent:

20170054250, Feb 23, 2017

Filed:

May 6, 2016

Appl. No.:

15/148494

Inventors:

- Cupertino CA, US
Paul Z. Yuan - San Jose CA, US
Xuan Liu - Champaign IL, US

International Classification:

H01R 13/631
H01R 13/642

Abstract:

A cable connector and methods for the assembly thereof are disclosed. The cable connector eliminates potential for short events during plug insertion, provides good contact resistance, and can support high speed data transactions. The cable connector further includes a rotating lock design that provides a secure connection.
