Peter John Newnham

US Patent:

20210300519, Sep 30, 2021

Filed:

Mar 27, 2020

Appl. No.:

16/832176

Inventors:

- Chicago IL, US
Max Tyler Breedlove - Seal Beach CA, US
Paul Diep - Bothell WA, US
Peter John Newnham - Mukilteo WA, US

Assignee:

The Boeing Company - Chicago IL

International Classification:

B64C 1/06
B64C 1/10
B64F 5/10

Abstract:

An aircraft tail assembly includes an aft fuselage section secured to a forward fuselage section, and includes a stiffener-reinforced pivot bulkhead defined by separate parts secured together by a first set of splices. A longeron extends longitudinally along the aft and forward fuselage sections, and includes a discontinuity adjacent a peripheral edge of the pivot bulkhead. The aircraft tail assembly includes a second set of splices that overlie the discontinuity. One of the second set of splices extends laterally over the longeron to bridge the discontinuity adjacent the peripheral edge of the pivot bulkhead, and another of the second set of splices extends longitudinally along the longeron to secure the longeron to the pivot bulkhead adjacent the discontinuity. A chord engages the peripheral edge of the pivot bulkhead to facilitate transfers of force loads from the bulkhead along a load path that includes the longerons and the splices.
