Philip E Taylor

US Patent:

44899653, Dec 25, 1984

Filed:

Nov 22, 1982

Appl. No.:

6/443380

Inventors:

Philip E. Taylor - Bloomfield Hills MI

Assignee:

General Motors Corporation - Detroit MI

International Classification:

E05C 112
E05C 700

US Classification:

292 34

Abstract:

A latching mechanism for a pair of relatively slidable overlapping window panels includes a pair of opposed fixed support blocks with bearing surfaces engageable with the outside surfaces of the window panels. A first wedging block is floatingly mounted between the window panels and has a bearing surface engageable with the inside surface of one window panel and a slanted wedging surface spaced from the inside surface of the other window panel. A latching lever, movable between operative and inoperative positions, is secured to a second wedging block which has a wedging surface engageable with the wedging surface of the first wedging block and a bearing surface engageable with the inside surface of the other window panel. In the operative position of the lever, the engagement of the wedging surfaces of the wedging blocks engages the bearing surfaces of the wedging blocks with the inside surfaces of respective window panels to wedge the panels against the bearing surfaces of the support blocks. When the lever is rotated to inoperative position, the second wedging block is moved out of engagement with the first wedging block, to allow the window panels to slide freely relative to each other.
