Raymond L Kostecki

US Patent:

42700809, May 26, 1981

Filed:

Dec 14, 1978

Appl. No.:

5/969299

Inventors:

Raymond T. Kostecki - Glenview IL

Assignee:

Sun Electric Corporation - Crystal Lake IL

International Classification:

H02J 704

US Classification:

320 24

Abstract:

An automatic apparatus and method for charging a storage battery from a source of electrical current. The charger includes a current control circuit for conducting regulated charging current through the battery in steps. A voltage monitoring circuit determines when the steps occur by monitoring battery voltage conditions. The steps are sequenced by a ring counter that varies the bias conditions on the current control circuit and voltage monitoring circuit as the steps occur.

US Patent:

39850803, Oct 12, 1976

Filed:

Oct 30, 1967

Appl. No.:

4/679261

Inventors:

Raymond T. Kostecki - Chicago IL

Assignee:

The United States of America as represented by the Secretary of the Navy - Washington DC

International Classification:

F42C 1304

US Classification:

102 702P

Abstract:

A device for use in an active-passive fuzing system to guard against the functioning of the fuze due to jamming signals transmitted by the target. A gate circuit is utilized to prevent an enabling signal to be passed to the warhead detonator until there is jamming signal fall-off in the guard detector and there is an increase in signal strength in the passive detector.

US Patent:

39315673, Jan 6, 1976

Filed:

Feb 8, 1974

Appl. No.:

5/440690

Inventors:

Raymond T. Kostecki - Glenview IL

Assignee:

Warwick Electronics Inc. - Chicago IL

International Classification:

G05F 158

US Classification:

323 9

Abstract:

In a DC power supply, a switching transistor and an inductor are connected in series between an unregulated DC supply and a DC output terminal. The output DC voltage is a function of the on to off ratio of the switching transistor. The switching period of the switching transistor is controlled by a load feedback circuit which compares the output voltage, as sensed by the voltage drop of the current through the switching transistor, with a sawtooth voltage from a synchronized oscillator. An overload detection circuit includes a diode and integrator coupled to a junction between the inductor and the switching transistor. When the switching transistor is turned off, the load current which was flowing through the switching transistor is diverted to the diode. The current through the diode is thus directly proportional to the load current. The load current is detected and causes disabling of the load feedback circuit when the load current rises above a predetermined level.
