US Patent:

20170232465, Aug 17, 2017

Filed:

Apr 28, 2017

Appl. No.:

15/582432

Inventors:

- WESTLAKE OH, US
Alec J. Babiarz - Encinitas CA, US
Nicholas Anthony Barendt - Fairview Park OH, US
Robert Ciardella - Rancho Santa Fe CA, US
James Everett Cooper - Vista CA, US
Kenneth S. Espenschied - Olmsted Township OH, US
Erik Fiske - Carlsbad CA, US
Christopher L. Giusti - San Marcos CA, US
Patrick R. Jenkins - Carlsbad CA, US
Alan Lewis - Carlsbad CA, US
Raymond Andrew Merritt - San Diego CA, US
Naoya Ian Nagano - Oceanside CA, US
Horatio Quinones - San Marcos CA, US
Thomas Ratledge - San Marcos CA, US
Joe Sherman - Fallbrook CA, US
Floriana Suriawidjaja - Carlsbad CA, US
Todd Weston - Vista CA, US

International Classification:

B05C 11/10
G05D 7/06
H05K 3/28
B05C 5/00

Abstract:

A viscous material noncontact jetting system has a jetting dispenser mounted for relative motion with respect to a surface. A control is operable to cause the jetting dispenser to jet a viscous material droplet that is applied to the surface as a viscous material dot. A device, such as a camera or weigh scale, is connected to the control and provides a feedback signal representing a size-related physical characteristic of the dot applied to the surface. The size-related physical characteristics of subsequently applied dots are controlled by heating and cooling, or adjusting a piston stroke in the jetting dispenser, in response to the size-related physical characteristic feedback. Dispensed material volume control and velocity offset compensation are also provided.
