Raymond A Stoner

US Patent:

20130048326, Feb 28, 2013

Filed:

Aug 31, 2011

Appl. No.:

13/223009

Inventors:

Raymond Stoner - Yuba City CA, US
Christopher John Galloway - Davis CA, US

International Classification:

B25D 17/00

US Classification:

173133

Abstract:

A hydraulic, pneumatic, or electric tool may include a spindle that is adapted for rotational movement. A swing arm may be coupled to the spindle such that the rotational motion of the spindle is transferred to the swing arm. The swing arm may make contact with an anvil such that the rotational motion of the swing arm causes the anvil to move in a first direction along a linear path. A piston may be operatively coupled to the anvil to follow the linear movement of the anvil. The piston may be adapted to interact with an energy storage medium when the swing arm moves the anvil in the first direction, thereby causing energy to be stored in the energy storage medium. As the swing arm continues to rotate, the swing arm may lose contact with the anvil, thus allowing the energy storage medium to urge the piston and the anvil in a second direction opposite the first direction.

US Patent:

20200361070, Nov 19, 2020

Filed:

Jul 10, 2020

Appl. No.:

16/926538

Inventors:

Raymond Stoner - Yuba City CA, US
Christopher John Galloway - Davis CA, US

International Classification:

B25D 9/04
B25D 9/12

Abstract:

A hydraulic, pneumatic, gasoline, diesel, or electric tool may include a spindle that is adapted for rotational movement. A swing arm may be coupled to the spindle such that rotational motion of the spindle is transferred to the swing arm. The swing arm makes contact with a piston such that the rotational motion causes the piston to move along a linear path. The piston may interact with an energy storage medium when the swing arm moves the piston in the first direction, causing energy to be stored in the energy storage medium. As the swing arm continues to rotate, the swing arm may lose contact with the piston, thus allowing the energy storage medium to urge the piston in a second direction opposite the first direction to strike an anvil. The swing arm may be a multiple roller swing arm. The energy storage medium may be a compound spring assembly.

US Patent:

20190321957, Oct 24, 2019

Filed:

Apr 18, 2018

Appl. No.:

15/956651

Inventors:

Raymond Stoner - Yuba City CA, US
Christopher John Galloway - Davis CA, US

International Classification:

B25D 9/04
B25D 11/04
B25D 9/12
B25D 9/10

Abstract:

A hydraulic, pneumatic, gasoline, diesel, or electric tool may include a spindle that is adapted for rotational movement. A swing arm may be coupled to the spindle such that rotational motion of the spindle is transferred to the swing arm. The swing arm makes contact with a piston such that the rotational motion causes the piston to move along a linear path. The piston may interact with an energy storage medium when the swing arm moves the piston in the first direction, causing energy to be stored in the energy storage medium. As the swing arm continues to rotate, the swing arm may lose contact with the piston, thus allowing the energy storage medium to urge the piston in a second direction opposite the first direction to strike an anvil. The swing arm may be a multiple roller swing arm. The energy storage medium may be a compound spring assembly.
