Richard F Foulke

US Patent:

6427903, Aug 6, 2002

Filed:

Feb 6, 1997

Appl. No.:

08/795543

Inventors:

Richard F. Foulke - Stoneham MA
Cord W. Ohlenbusch - Andover MA

Assignee:

Speedline Technologies, Inc. - Franklin MA

International Classification:

B23K 3512

US Classification:

228246, 228 41, 228 563, 228 8, 228105, 228245, 228180, 228253

Abstract:

An apparatus for placing an array of solder balls on a substrate includes a carrier plate having an array of holes therethrough. Each hole is capable of holding a solder ball. A ball placement head having an array of pins is aligned with a desired pattern of solder balls held by the carrier plate. The array of pins push the pattern of solder balls through the holes in the carrier plate onto the substrate.

US Patent:

6641030, Nov 4, 2003

Filed:

Feb 19, 1999

Appl. No.:

09/253150

Inventors:

Gary Freeman - Beverly MA
Thomas Nowak, Jr. - N. Hampton NH
Thomas Purcell - Haverhill MA
A. Jason Mirabito - Hull MA
Thomas M. Sullivan - Salem NH
Richard F. Foulke - Stoneham MA
Cord W. Ohlenbusch - Andover MA

Assignee:

Speedline Technologies, Inc. - Haverhill MA

International Classification:

B23K 3512

US Classification:

228246, 228245, 228 39, 228 41, 22818022, 257737, 257738

Abstract:

An apparatus for placing spheres at predetermined positions on a substrate. The apparatus includes a platform to support the substrate at a first sphere placement position in the apparatus, and a placement station disposed above the platform that places spheres at locations on the substrate. The placement station includes a first container having a chamber to contain spheres, and a first carrier tray having a substantially horizontal upper surface that forms a lower surface of the chamber. The upper surface has a first section and a second section, the second section having a plurality of holes formed therein to receive spheres. The first carrier tray is movable to position the second section between a fill position beneath the first container and a place position disposed over the first sphere placement position. The placement station is constructed and arranged to fill the plurality of holes with spheres when the second section is in the fill position, and place the spheres at the predetermined positions on the substrate when the second section is in the place position.

US Patent:

6690993, Feb 10, 2004

Filed:

Jun 27, 2001

Appl. No.:

09/892945

Inventors:

Richard F. Foulke - Stoneham MA
Cord W. Ohlenbusch - Andover MA
Takman Lui - Andover MA

Assignee:

R. Foulke Development Company, LLC - Salem NH

International Classification:

G06F 700

US Classification:

700218, 700259, 414217, 4142171, 414277, 414937, 414938, 414939

Abstract:

A reticle storage system includes a reticle rack having a series of lateral slots, each for storing a reticle. Access to the reticles is provided on a lateral side of the rack. The enclosure has a series of doors for providing access to the reticles in the slots. An air circulation system flows filtered air past the reticles in the rack to prevent contaminants from accumulating on the reticles. The air circulation system is capable of providing positive air pressure within the enclosure with one door open, thereby preventing contaminants from entering the enclosure through the open door.

US Patent:

20040149084, Aug 5, 2004

Filed:

Sep 5, 2002

Appl. No.:

10/236061

Inventors:

Jung-Hoon Chun - Sudbury MA, US
Richard Foulke - Stoneham MA, US
Juan Rocha - Sunnyvale CA, US
Nannaji Saka - Cambridge MA, US

Assignee:

Massachusetts Institute of Technology - Cambridge MA

International Classification:

B22F009/08

US Classification:

075/332000

Abstract:

An apparatus and method of forming fluxless solder balls includes forming solder balls from a supply of solder. A coating is formed on the solder balls for limiting naturally occurring oxide growth on the solder balls before significant natural oxide growth on the solder balls has occurred. The coating allows the solder balls to be soldered without using flux.

US Patent:

20040158348, Aug 12, 2004

Filed:

Feb 9, 2004

Appl. No.:

10/774958

Inventors:

Richard Foulke - Stoneham MA, US
Richard Foulke - Hampstead NH, US
Cord Ohlenbusch - Andover MA, US
Takman Lui - Andover MA, US

Assignee:

R. Foulke Development Company, LLC - Salem NH

International Classification:

G06F007/00

US Classification:

700/218000, 700/259000, 414/217000, 414/217100, 414/277000, 414/937000, 414/938000, 414/939000

Abstract:

A reticle storage system includes a reticle rack having a series of lateral slots, each for storing a reticle. Access to the reticles is provided on a lateral side of the rack. The enclosure has a series of doors for providing access to the reticles in the slots. An air circulation system flows filtered air past the reticles in the rack to prevent contaminants from accumulating on the reticles. The air circulation system is capable of providing positive air pressure within the enclosure with one door open, thereby preventing contaminants from entering the enclosure through the open door.

US Patent:

20040185682, Sep 23, 2004

Filed:

Aug 6, 2003

Appl. No.:

10/635231

Inventors:

Richard Foulke - Stoneham MA, US
Richard Foulke - Hampstead NH, US

Assignee:

R. Foulke Development Company, LLC - Salem NH

International Classification:

H01L021/00
G08C019/22
H04Q009/00

US Classification:

438/800000, 340/870070

Abstract:

A reticle assembly includes a reticle with a reticle plate. A radio frequency device is positioned on the reticle for providing information regarding the reticle to a reader by radio frequency.

US Patent:

20040191032, Sep 30, 2004

Filed:

Jul 18, 2003

Appl. No.:

10/622261

Inventors:

Richard Foulke - Stoneham MA, US
Richard Foulke - Hampstead NH, US
Carl Ito - Scottsdale AZ, US

Assignee:

R. Foulke Development Company, LLC - Salem NH

International Classification:

B65G001/00

US Classification:

414/280000

Abstract:

An extendable arm for placing and moving items includes a base and an arm unit movably mounted to the base. The arm unit is configured for linear movement in a first direction relative to the arm unit for extending beyond the base in the first direction and for linear movement in a second direction relative to the arm unit which is opposite to the first direction for extending beyond the base in the second direction.

US Patent:

46038973, Aug 5, 1986

Filed:

May 20, 1983

Appl. No.:

6/496460

Inventors:

Richard F. Foulke - Carlisle MA
Kenneth A. Winchell - Melrose MA

Assignee:

Poconics International, Inc. - Woburn MA

International Classification:

B65G 1732

US Classification:

294 641

Abstract:

Apparatus that uses a suction engagement element to transport semiconductor wafers between processing boats and detects when suction engagement has not occurred despite the engagement element having been moved toward a wafer a distance sufficient to enable said engagement, and then adjusts the position of the engagement element relative to the object (e. g. , by backing up and trying again or by pivoting the engagement element) to facilitate the suction engagement.
