Richard R Heye

US Patent:

8291295, Oct 16, 2012

Filed:

Aug 11, 2009

Appl. No.:

12/539417

Inventors:

Eliyahou Harari - Saratoga CA, US
Richard R. Heye - Sunnyvale CA, US
Robert D. Selinger - San Jose CA, US
Menahem Lasser - Kohav-Yair, IL

Assignee:

SanDisk IL Ltd. - Kfar Saba

International Classification:

G11C 29/00

US Classification:

714763, 36518509, 36518533

Abstract:

A NAND controller for interfacing between a host device and a flash memory device (e. g. , a NAND flash memory device) fabricated on a flash die is disclosed. In some embodiments, the presently disclosed NAND controller includes electronic circuitry fabricated on a controller die, the controller die being distinct from the flash die, a first interface (e. g. a host-type interface, for example, a NAND interface) for interfacing between the electronic circuitry and the flash memory device, and a second interface (e. g. a flash-type interface) for interfacing between the controller and the host device, wherein the second interface is a NAND interface. According to some embodiments, the first interface is an inter-die interface. According to some embodiments, the first interface is a NAND interface. Systems including the presently disclosed NAND controller are also disclosed.

US Patent:

20110041039, Feb 17, 2011

Filed:

Aug 11, 2009

Appl. No.:

12/539394

Inventors:

Eliyahou Harari - Saratoga CA, US
Richard R. Heye - Sunnyvale CA, US
Robert D. Selinger - San Jose CA, US

International Classification:

G06F 12/02
H03M 13/05
G06F 11/10
G06F 12/14

US Classification:

714773, 711103, 713193, 711E12008, 714E11032

Abstract:

The embodiments described herein provide a controller and method for interfacing between a host controller in a host and a flash memory device. In one embodiment, a controller comprises a first NAND interface, a second NAND interface, and one or more of the following modules: a data scrambling module, a column replacement module, and a module that manages at least one of bad blocks and spare blocks. Other embodiments are disclosed, and each of the embodiments can be used alone or together in combination.

US Patent:

20130111113, May 2, 2013

Filed:

Aug 28, 2012

Appl. No.:

13/596926

Inventors:

Eliyahou Harari - Saratoga CA, US
Richard R. Heye - Sunnyvale CA, US
Robert D. Selinger - San Jose CA, US
Menahem Lasser - Kohav-Yair, IL

International Classification:

G06F 12/02

US Classification:

711103

Abstract:

A NAND controller for interfacing between a host device and a flash memory device (e.g., a NAND flash memory device) fabricated on a flash die is disclosed. In some embodiments, the presently disclosed NAND controller includes electronic circuitry fabricated on a controller die, the controller die being distinct from the flash die, a first interface (e.g. a host-type interface, for example, a NAND interface) for interfacing between the electronic circuitry and the flash memory device, and a second interface (e.g. a flash-type interface) for interfacing between the controller and the host device, wherein the second interface is a NAND interface. According to some embodiments, the first interface is an inter-die interface. According to some embodiments, the first interface is a NAND interface. Systems including the presently disclosed NAND controller are also disclosed. Methods for assembling the aforementioned systems, and for reading and writing data using NAND controllers are also disclosed.

US Patent:

54308887, Jul 4, 1995

Filed:

Oct 26, 1993

Appl. No.:

8/143509

Inventors:

Richard T. Witek - Littleton MA
Douglas D. Williams - Pepperell MA
Timothy J. Stanley - Leominster MA
David M. Fenwick - Chelmsford MA
Douglas J. Burns - Billerica MA
Rebecca L. Stamm - Newton MA
Richard Heye - Somerville MA

Assignee:

Digital Equipment Corporation - Maynard MA

International Classification:

G06F 1208

US Classification:

395800

Abstract:

A load/store pipeline in a computer processor for loading data to registers and storing data from the registers has a cache memory within the pipeline for storing data. The pipeline includes buffers which support multiple outstanding read request misses. Data from out of the pipeline is obtained independently of the operation of the pipeline, this data corresponding to the request misses. The cache memory can then be filled with the requested for data. The provision of a cache memory within the pipeline, and the buffers for supporting the cache memory, speed up loading operations for the computer processor.

US Patent:

51485362, Sep 15, 1992

Filed:

Jul 25, 1988

Appl. No.:

7/224483

Inventors:

Richard T. Witek - Littleton MA
Douglas D. Williams - Pepperell MA
Timothy J. Stanley - Leominster MA
David M. Fenwick - Chelmsford MA
Douglas J. Burns - Billerica MA
Rebecca L. Stamm - Newton MA
Richard Heye - Somerville MA

Assignee:

Digital Equipment Corporation - Maynard MA

International Classification:

G06F 938

US Classification:

395425

Abstract:

A load/store pipeline in a computer processor for loading data to registers and storing data from the registers has a cache memory within the pipeline for storing data. The pipeline includes buffers which support multiple outstanding read request misses. Data from out of the pipeline is obtained independently of the operation of the pipeline, this data corresponding to the request misses. The cache memory can then be filled with the data that has been requested. The provision of a cache memory within the pipeline, and the buffers for supporting the cache memory, speed up loading operations for the computer processor.

US Patent:

53595475, Oct 25, 1994

Filed:

Jun 26, 1992

Appl. No.:

7/904784

Inventors:

William H. Cummins - Tewksbury MA
R. Stephen Polzin - Morgan Hill CA
Richard Heye - Sunnyvale CA

Assignee:

Digital Equipment Corporation - Maynard MA

International Classification:

G06F 1122

US Classification:

364580

Abstract:

A method and apparatus for testing complex processor-based computer modules and their associated computer systems by allowing the normal initialization path between a memory component storing code utilized during initialization and the processor to be interrupted and test code from an external test system to be substituted for initialization code. Following initialization, a two-way communication link between the processor and the test system is created to allow interactive testing and status reporting. The testing method and apparatus maximizes the likelihood of precisely identifying defects on the module under test.

US Patent:

20140250348, Sep 4, 2014

Filed:

May 15, 2014

Appl. No.:

14/278672

Inventors:

- Plano TX, US
Richard R. Heye - Sunnyvale CA, US
Robert D. Selinger - San Jose CA, US

Assignee:

SanDisk Technologies Inc. - Plano TX

International Classification:

G06F 11/10
G11C 29/00
G06F 12/02

US Classification:

714773, 711103

Abstract:

The embodiments described herein provide a controller and method for interfacing between a host controller in a host and a flash memory device. In one embodiment, a controller comprises a first NAND interface, a second NAND interface, and one or more of the following modules: a data scrambling module, a column replacement module, and a module that manages at least one of had blocks and spare blocks. Other embodiments are disclosed, and each of the embodiments can be used alone or together in combination.
