Richard A Rolfe

US Patent:

62561499, Jul 3, 2001

Filed:

Sep 28, 1998

Appl. No.:

9/162073

Inventors:

Richard W. Rolfe - Biddeford ME

International Classification:

G02B 2710
G02F 500
B29D 1100

US Classification:

359619

Abstract:

A method is provided for producing lenticular lens sheets having improved optical characteristics. The method includes the steps of providing a platen having a series of grooves formed therein so as to define a series of parallel ridges, positioning a sheet of formable material next to the platen, heating the sheet to render it formable, and applying a pressure differential to the sheet that forces the sheet into contact with the ridges on the platen. This process produces a lenticular lens sheet having a plurality of parallel lenticules. Each lenticule has a catenary surface having a non-uniform radius of curvature that is greatest at the center of the lenticule and smallest at its outer edges.

US Patent:

55534449, Sep 10, 1996

Filed:

Sep 15, 1994

Appl. No.:

8/306466

Inventors:

Craig Lovecky - Old Orchard Beach ME
Richard Rolfe - Biddeford ME
Alan B. Lowry - Canton MA
Robert Steller - Old Orchard Beach ME

Assignee:

Shape Inc. - Biddeford ME

International Classification:

B65B 2300
B65D 8116

US Classification:

53453

Abstract:

A container for a PC card including a relatively hard base pivotably connected by a hinge to a cover. A resilient tray is positioned within the base. The cover can be kept in a closed position by a latch. An outer edge of the tray attaches to a peripheral lip on the base to form a bumper and a seal between the base and cover when the container is closed. The edge also prevents shear movement of the cover relative to the base when the container is dropped on a corner. The hinge and latch are inboard of the outer edge of the tray so that they aren't disturbed if the container is dropped. The tray includes a central receptacle that receives the PC card. Between the PC card receptacle and the outer edge of the tray there is formed a bellows-like member which tangents the cover and base and physically isolates the PC card receptacle from the cover and base. The bellows-like member allows the PC card receptacle to move freely of the base and cover, so should the container with a PC card therein be dropped, the PC card can "float" in the container. It is the bellows that absorbs the shock, not the cover, base or PC card receptacle.

US Patent:

51996618, Apr 6, 1993

Filed:

Mar 28, 1991

Appl. No.:

7/676380

Inventors:

Anthony L. Gelardi - Cape Porpoise ME
Craig Lovecky - Old Orchard Beach ME
Alan Lowry - Canton MA
Richard Rolfe - Biddeford ME
W. Tyler Fitzsimmons - Washington DC

Assignee:

Shape Inc. - Biddeford ME

International Classification:

G03B 104
G11B 1532

US Classification:

242199

Abstract:

A reel spring including a wire having a flat central portion and two angled arms, each terminating in substantially planar pads, curved portions or pivot buttons. The flat central portion includes two spaced, open loops which receive corresponding projections formed on the cassette cover. The pads, curved portions or pivot buttons abut and bias the tape reel hubs downwardly when the cassette cover and base are mated. The methods of assembly include the steps of moving the loops against the projections until the corresponding projections are received by the loops and caulking or swaging the projections. The wire reel spring can be removed by merely moving the wire reel spring in the opposite direction.

US Patent:

56007191, Feb 4, 1997

Filed:

Feb 14, 1996

Appl. No.:

8/601647

Inventors:

Craig S. Lovecky - Old Orchard Beach ME
Richard Rolfe - Biddeford ME
Alan B. Lowry - Canton MA

Assignee:

Shape Inc. - Biddeford ME

International Classification:

H04M 100

US Classification:

379438

Abstract:

A portable telephone line storage device, including a housing, a manually rotatable reel within the housing, a telephone line having a first end with a telephone jack, and a second end with a telephone jack, wherein said line is movable between a first retracted position inside the housing, and a second extended position where a majority of the line is outside of the housing, and wherein the telephone jacks are positioned inside the housing in the first position, and outside the housing in the second position.

US Patent:

46554084, Apr 7, 1987

Filed:

Mar 19, 1986

Appl. No.:

6/842368

Inventors:

Anthony L. Gelardi - Cape Porpoise ME
Diane Pruneau - Saco ME
Richard Rolfe - Madison CT

Assignee:

Shape Inc. - Biddeford ME

International Classification:

B65H 2026

US Classification:

242 5519A

Abstract:

A continuous loop tape cassette for use with an external tape player/recorder apparatus, having a cassette base, a cover and a separate tape guide positioned therebetween. The separate tape guide includes an elongated bridge molded of a low friction plastic and having substantially planar top and bottom surfaces, left and right ends with curved, relatively flat, front surfaces which are slightly slanted relative to the substantially planar top and bottom bridge surfaces, and a flange formed integrally of the front top surface of each end. In addition, locating holes are formed at each left and right end to receive corresponding projections formed on the cassette base and to orient the bridge relative to the tape cassette. Finally, there is provided between the left and right ends a leaf spring having a relatively soft, tape contacting member thereon for exerting a uniform pressure on the running tape as it crosses the magnetic head of the external tape player/recorder apparatus. The curved, relatively flat, front surfaces of the left and right ends, together with the flange and tape contacting member define the tape guiding surface of the tape guide.

US Patent:

47934808, Dec 27, 1988

Filed:

Dec 16, 1986

Appl. No.:

6/942266

Inventors:

Anthony L. Gelardi - Cape Porpoise ME
John Gelardi - Cape Porpoise ME
Richard Rolfe - Biddeford ME
Alan B. Lowry - Canton MA
Craig Lovecky - Old Orchard Beach ME

Assignee:

Shape Inc. - Biddeford ME

International Classification:

B65D 8557

US Classification:

206312

Abstract:

A storage container for a recording medium and related methods of manufacturing and assembling same are described. The storage container includes: a base; a recording medium holder having a compact disc clamp and being pivotally attached at a first end thereof to a first end of the base and the other end being a free end for movement relative to the base; a cover pivotally attached at a first end thereof to the first end of the base; and an actuator for moving the holder relative to the base. When the cover is lifted relative to the base, the actuator causes the holder to move from the first position to the second position and to automatically present the recording medium away from the base for facilitated removal and replacement. In one embodiment, the clamp can include two portions, one of which is a semicircular portion formed on the holder and the other of which is a raised semicircular portion formed on a tongue pivotally attached to the holder. The tongue is movable relative to the holder such that the raised portion is capable of engaging the compact disc aperture for storage or releasing the aperture for removal of the disc.

US Patent:

51690888, Dec 8, 1992

Filed:

Oct 17, 1990

Appl. No.:

7/598961

Inventors:

Craig Lovecky - Old Orchard Beach ME
Alan Lowry - Canton MA
W. Tyler Fitzsimmons - Washington DC
Richard Rolfe - Biddeford ME

Assignee:

Shape, Inc. - Biddeford ME

International Classification:

G11B 2304

US Classification:

242199

Abstract:

A short leg and coil of a torsion spring fit on a dust door polar member and a long leg having a first end connected to the coil and a second free end extends therefrom. An offset is formed between the first and second ends of the long leg and is received by a cassette cover and the free end engages a perpendicular projection formed on a dust door latch. In a second embodiment, a lower portion of the latch can flex relative to an upper portion, and a leaf spring is integrally formed to extend from the upper portion. The dust door polar member has a cam which cooperates with the leaf spring. In the first embodiment, when the latch is actuated by a pin the dust door is unlatched and rotated to the open position. When the pin is released, the long leg biases the latch back into a latched position and, simultaneously, the rest of the spring closes the door. In the second embodiment, the pin flexes the lower portion of the latch relative to the upper portion, and the cam loads the leaf spring upon opening the door.

US Patent:

51582449, Oct 27, 1992

Filed:

Aug 1, 1990

Appl. No.:

7/562004

Inventors:

Anthony Gelardi - Cape Porpoise ME
Craig Lovecky - Old Orchard Beach ME
Robert Barstow - Alfred ME
Alan Lowry - Canton MA
Richard Rolfe - Biddeford ME

Assignee:

Shape Inc. - Biddeford ME

International Classification:

G11B 2304

US Classification:

242199

Abstract:

Integrally molded dust door latches for a video cassette. The latch never needs to be preloaded and includes a planar latch body having a flexing member formed integrally therein to impart inherent spring action to the latch. The latch includes two lateral supports and a first and second projections which enter openings formed in the cassette base. The latch is assembled in the cassette such that the latch can flex or deflect via the flexing member when pressure is applied to one of the projections.
