Robert E Dooley

US Patent:

6609420, Aug 26, 2003

Filed:

Apr 23, 2001

Appl. No.:

09/839738

Inventors:

Robert B. Dooley - Canton MA

Assignee:

The United States of America as represented by the Secretary of the Army - Washington DC

International Classification:

G01L 514

US Classification:

73167, 738656, 738653

Abstract:

The invention features a modified catch tube component capable of performing the function of the conventional catch tube and the conventional MEM simultaneously. The catch tube will also feature a capability to accept modular units of mass for adjusting the available angular momentum (of the spinning catch tube) as well as to incrementally adjust inertial resistance for controlling post-impact translational motion. The safety and performance enhancements of the modified spinner are achieved by the above mentioned integration of the MEM with the catch tube. This invention will eliminate MEM free flight and prevent excessively soft, or excessively hard projectile impacts. Equipment such as rails and wheel sets are used to assure that the motion of the catch tube is constrained to translation and to rotation. The invention contrasts conventional spinners in that the motion of a conventional catch tube is limited to rotation only and the MEM to translation and rotation.

US Patent:

7083140, Aug 1, 2006

Filed:

Sep 14, 2004

Appl. No.:

10/939418

Inventors:

Robert B. Dooley - Canton MA, US

Assignee:

The United States of America as represented by the Secretary of the Army - Washington DC

International Classification:

F42B 10/14

US Classification:

244 327, 244 31, 244 324, 244 45 R, 244 46, 244 49, 102501

Abstract:

A method and structure for a full-bore artillery projectile fin deployment device comprising a projectile stabilization fin comprising an aperture and a movable pawl; a rod comprising a head portion and a shaft portion terminating with a beveled tip configured for engaging the pawl; a tailboom configured for housing the fin, wherein the tailboom comprises a hollow bore configured for receiving the rod; a pin slotted through the aperture and attached to the tailboom; and a bias member adjacent to the head portion of the rod. The rod is slotted to simultaneously engage a plurality of fins. The tailboom comprises a forward end and a rearward end and a slot configured for permitting the fin to articulate out of the tailboom, and wherein the tailboom connects to a projectile. Additionally, the power source for the device is the naturally occurring launch accelerations.

US Patent:

50385020, Aug 13, 1991

Filed:

Oct 3, 1989

Appl. No.:

7/416366

Inventors:

Robert E. Dooley - Sagamore Beach MA
Kimberly A. Felice - Sagamore Beach MA

International Classification:

D06F 8102

US Classification:

38106

Abstract:

A workstation tray device for easy connection with a plurality of collapsible ironing board configurations, for temporary but secure storage of containers of compositions applied to objects being ironed, in hinged cooperation for retractable storage in connection with the ironing board without being detached therefrom. The device consisting of a tray member of resilient material for attachment to a ironing board by of fingers for receiving a hinged adjustable collar for clamping to one ironing board leg, and by two support arms each movably attached, at one end by bolt to the flat end of the board member, and at the other end to a bracket attached to the tray such that the shelf is horizontally disposed under the board in convenient close proximity having adequate clearance for storage of items, all without interfering with the legs and feet of the operator. The arms have arch members hingeably attached to strut to cooperate with the tray.

US Patent:

51367980, Aug 11, 1992

Filed:

Dec 21, 1990

Appl. No.:

7/632164

Inventors:

Robert E. Dooley - Sagamore Beach MA
Kimberly A. Felice - Sagamore Beach MA

International Classification:

D06F 8102

US Classification:

38106

Abstract:

A workstation tray device for easy connection with a plurality of collapsible ironing board configurations, for temporary but secure storage of containers of compositions applied to articles being ironed, in hinged cooperation for retractable storage in connection with the ironing board without being detached therefrom. The device consisting of a tray member of resilient material for attachment to a ironing board by fingers for receiving a hinged adjustable collar for clamping to one ironing board leg, and by two support arms each movably attached, at one end by a bolt to the flat end of the board member, and at the other end to a bracket attached to the tray such that the shelf is horizontally disposed under the board in convenient close proximity having adequate clearance for storage of items, all without interfering with the legs and feet of the operator. The arms have arch members hingeably attached to strut to cooperate with the tray.
