Robert E Dutton

US Patent:

6564619, May 20, 2003

Filed:

Sep 19, 2001

Appl. No.:

09/955765

Inventors:

Robert E. Dutton - Louisville CO
Chad Steele - Denver CO

Assignee:

Micro Motion, Inc. - Boulder CO

International Classification:

G01F 174

US Classification:

73 6144, 7386104

Abstract:

A method and system of performing multiphase flow measurements. The method includes separating an incoming multiphase flow into a majority liquid component and a majority gas component. The majority liquid component comprises a water component and an oil component. The method further includes determining if the majority liquid component includes entrained gas. If the majority liquid component is substantially free from entrained gas, then the method further includes determining a water-cut of the majority liquid component, determining a density of the majority liquid component using a Coriolis flowmeter, and processing the water-cut and the density of the majority liquid component to determine a density of the oil component.

US Patent:

6810719, Nov 2, 2004

Filed:

Feb 5, 2003

Appl. No.:

10/358844

Inventors:

Robert E. Dutton - Louisville CO
Chad Steele - Denver CO

Assignee:

Micro Motion, Inc. - Boulder CO

International Classification:

G01F 174

US Classification:

73 6144, 7386104

Abstract:

A fully automated Coriolis-based well system which can deliver accurate volumetric flow rate measurements in three phase flow. Measurements are performed according to a process including using N equations and N unknowns technique.

US Patent:

7013715, Mar 21, 2006

Filed:

Aug 19, 2004

Appl. No.:

10/922185

Inventors:

Robert E. Dutton - Louisville CO, US
Chad Steele - Denver CO, US

Assignee:

Micro Motion, Inc. - Boulder CO

International Classification:

G01F 1/74
G01F 15/08

US Classification:

73 6144, 7386104

Abstract:

A fully automated Coriolis-based well system which can deliver accurate volumetric flow rate measurements in three phase flow. Measurements are performed according to a process including using N equations and N unknowns technique.

US Patent:

7013740, Mar 21, 2006

Filed:

Dec 18, 2003

Appl. No.:

10/737856

Inventors:

Robert E. Dutton - Louisville CO, US
Wade M. Mattar - Wrentham MA, US

Assignee:

Invensys Systems, Inc. - Foxboro MA

International Classification:

G01F 1/84

US Classification:

73861354

Abstract:

A steam measurement system includes a Coriolis flowmeter associated with a vibratable flowtube to receive a flow of wet steam. A first sensor is associated with the flowtube to relay information about a motion of the flowtube by way of a first sensor signal. A second sensor determines a property of the flow and relays the property by way of a second sensor signal. A computing device receives the first and second sensor signals and is configured to calculate a steam quality of the flow from the first and second sensor signals. The computing device also may calculate the total heat energy flow rate of the flow. Other implementations may include a full or partial separator to separate the flow of wet steam into a substantially gas flow and a substantially liquid flow and a second Coriolis meter.

US Patent:

7231835, Jun 19, 2007

Filed:

Feb 1, 2006

Appl. No.:

11/344046

Inventors:

Robert E. Dutton - Louisville CO, US
Wade M. Mattar - Wrentham MA, US

Assignee:

Invensys Systems, Inc. - Foxboro MA

International Classification:

G01L 7/08

US Classification:

73861354

Abstract:

A steam measurement system includes a Coriolis flowmeter associated with a vibratable flowtube to receive a flow of wet steam. A first sensor is associated with the flowtube to relay information about a motion of the flowtube by way of a first sensor signal. A second sensor determines a property of the flow and relays the property by way of a second sensor signal. A computing device receives the first and second sensor signals and is configured to calculate a steam quality of the flow from the first and second sensor signals. The computing device also may calculate the total heat energy flow rate of the flow. Other implementations may include a full or partial separator to separate the flow of wet steam into a substantially gas flow and a substantially liquid flow and a second Coriolis meter.

US Patent:

7249500, Jul 31, 2007

Filed:

Feb 5, 2003

Appl. No.:

10/542119

Inventors:

Robert E. Dutton - Louisville CO, US
Christopher M. Russell - Cypress TX, US

Assignee:

Micro Motion, Inc. - Boulder CO

International Classification:

E21B 47/10

US Classification:

7315232

Abstract:

A measurement system () is disclosed comprising a Coriolis flow meter () and a control system (). A base fluid () is first flowed through the Coriolis flow meter. The Coriolis flow meter measures a density of the base fluid and transmits a base fluid density measurement to the control system. A proppant () is then added to the base fluid to create a fracture fluid (). The fracture fluid is then flowed through the Coriolis flow meter. The Coriolis flow meter measures a density of the fracture fluid and transmits a fracture fluid density measurement to the control system. The control system determines an amount of proppant in the fracture fluid based on the base fluid density measurement, the fracture fluid density measurement, and a density of the proppant.

US Patent:

RE40095, Feb 26, 2008

Filed:

May 6, 2003

Appl. No.:

10/430879

Inventors:

Robert E. Dutton - Louisville CO, US

Assignee:

Micro Motion, Inc. - Boulder CO

International Classification:

G01F 1/84

US Classification:

73861356, 73861357, 73861355

Abstract:

A Coriolis flowmeter is operable as a vibrating tube densitometer where a flowtube is driven to vibrate at a fundamental frequency from which density of the material flowing through the flowtube may be calculated. The drive gain is monitored as an indicator of multiphase flow including gas and liquid components where a substantial increase in drive gain indicates gas damping of the flowtube vibrations due to a transient bubble entering the flowtube. The gas damping effects of the transient bubble and the correspondingly reduced density readings are remediated by the use of historical density measurements corresponding to periods of flow when no transient bubble has entered the flowtube.

US Patent:

7337084, Feb 26, 2008

Filed:

Jun 21, 2005

Appl. No.:

11/157157

Inventors:

Robert E Dutton - Louisville CO, US

Assignee:

Invensys Systems, Inc. - Foxboro MA

International Classification:

G01F 1/12
G01F 1/50
G01F 25/00

US Classification:

702100

Abstract:

Descriptions are provided for implementing flowmeter zero checking techniques. In operating a flowmeter, it may be the case that, even if previously calibrated, the flowmeter will produce erroneous measurements, e. g. , will indicate a non-zero flow during a period of zero flow. Therefore, zero checking features are provided that allow for fast and accurate determinations of the zero-flow values, for use in adjusting later measurements. The zero-checking features include a button attached to an exterior of a flowmeter, so that it is easily accessible to an operator of the flowmeter. The button, in conjunction with an internal zero checking system, allows for a display of a zero value in response to a request from the operator of the flowmeter.
