US Patent:

6364976, Apr 2, 2002

Filed:

Dec 4, 2000

Appl. No.:

09/729232

Inventors:

Todd Fletemier - Gowen MI
Robert Ette - OFallon MO
Richard Long - Lincoln Park MI

Assignee:

Findlay Industries, Inc. - Troy MI

International Classification:

B32B 2712

US Classification:

156 622, 156148, 156279, 1563096, 156324, 264112

Abstract:

A laminated panel-type structure particularly suited for vehicle interior applications such as headliners and door panels has a multiple denier polyester fiber core and randomly oriented structural reinforcing fibers. The laminated structure has superior sound attenuation properties resulting from a core of intertwined polyester fibers of differing deniers, with preferably relatively larger denier fibers on exterior areas of the core and some bicomponent fibers, short non-woven reinforcing fiber strands which are randomly attached and intertwined with the core on opposing major sides of the core, an impervious polymer film with a low melt layer which retains the reinforcing fibers against one side of the core and is attached to a scrim layer, and a polymer web on an opposite side of the core which retains the reinforcing fiber strands on the opposing major side of the core and to which a cover stock is applied. The invention further includes a method of manufacturing the laminated structure wherein the various layers are sequentially unfurled from spools, passed through nip rollers at points of various subcombinations of materials and layers, the reinforcing fiber strands are randomly distributed on to the carrying layers from hoppers or directly from a fiber chopping device, and the completed laminated structure is cut and molded.
