Robert Philip Mallette

US Patent:

46967060, Sep 29, 1987

Filed:

Oct 31, 1985

Appl. No.:

6/793135

Inventors:

Kevin W. Griffin - Titusville FL
Robert P. Mallette - Cocoa Beach FL

International Classification:

B32B 3112

US Classification:

156 62

Abstract:

A logic design aid is produced by the use of distinct self-adhesive logic symbols. The logic symbols are applied to a firm dispenser board with a predetermined location. The dispenser board has a sticky material that allows the logic symbols and dispenser board to be orientated in any configuration in space. The distinct logic symbols are designed so that they can be easily removed without damage to the surface and reapplied to another position. The surface of each logic symbol has a blank area to allow text description to be entered to identify the logic process. The logic symbols are well suited for computer program flowchart development and electronic circuit design drawings.
