Robert J Marcinkowski

US Patent:

6606779, Aug 19, 2003

Filed:

Mar 9, 2001

Appl. No.:

09/803254

Inventors:

Brandon Verbrugge - Towson MD
Robert J. Marcinkowski - Cockeysville MD
Earl M. Ortt - Bel Air MD

Assignee:

Black Decker Inc. - Newark DE

International Classification:

H02K 1516

US Classification:

29596, 310154

Abstract:

A power tool includes a motor with a flux ring. The flux ring includes a ring member with a first and second end. The ends are positioned with respect to one another such that the ends move towards and away from one another during compressing and expanding of the ring. At least one anchor is unitarily formed with the ring. A pair of magnets are coupled with unitarily formed anchors to couple the pair of magnets with the ring. The magnets are coupled with the ring such that the ring may be compressed and expanded with the magnets secured in the ring.

US Patent:

6672402, Jan 6, 2004

Filed:

Dec 27, 2001

Appl. No.:

10/036011

Inventors:

Earl M. Ortt - Bel Air MD
Michael C. Doyle - Baldwin MD
Robert J. Marcinkowski - Cockeysville MD

Assignee:

Black Decker Inc. - Newark DE

International Classification:

B23B 4502

US Classification:

173 1, 173216, 173217, 310 47, 310 50

Abstract:

A motor end cap and output device housing is provided that includes a motor end plate having an output device attachment area and a output device housing having a motor end plate attachment area. The output device attachment area includes a locking tab that mates with a slot portion in the output device housing to interlock the two together. As a result, the motor end plate can be conveniently attached to the output device housing without requiring extra fasteners.

US Patent:

6713916, Mar 30, 2004

Filed:

Oct 31, 2002

Appl. No.:

10/286935

Inventors:

Robert B. Williams - Baltimore MD
Robert J. Marcinkowski - Cockeysville MD
Earl M. Ortt - Bel Air MD
Bradley J. Mealy - Abingdon MD

Assignee:

Black Decker Inc. - Newark DE

International Classification:

H02K 500

US Classification:

310 89, 310 58, 310 59

Abstract:

A field case housing has a substantially cylindrical wall segment, an end segment and a flange all having a substantially constant wall thickness. The flange has reinforcing ribs connected to the wall segment and aperture reinforcing bosses. The end segment, the wall segment and the flange are formed as a single, integral part adapted to reduce warping of the housing during molding. A cylindrical guide member is located in the field case housing and a conical guide member is located in the fan baffle. The cylindrical guide member is adapted to insure a screw passing through the cylindrical guide member is guided to a point within the conical guide member. The fan baffle has a transverse wall with an aperture and guide walls extending adjacent the aperture. The guide walls are adapted to guide an armature past the magnets without contacting and damaging them.

US Patent:

6750579, Jun 15, 2004

Filed:

Jul 3, 2002

Appl. No.:

10/189688

Inventors:

Brandon Verbrugge - Towson MD
Robert J. Marcinkowski - Cockeysville MD
Earl M. Ortt - Bel Air MD

Assignee:

Black Decker Inc. - Newark DE

International Classification:

H02K 117

US Classification:

31015408, 31015403

Abstract:

A power tool includes a motor with a flux ring. The flux ring includes a ring member with a first and second end. The ends are positioned with respect to one another such that the ends move towards and away from one another during compressing and expanding of the ring. At least one anchor is unitarily formed with the ring. A pair of magnets are coupled with unitarily formed anchors to couple the pair of magnets with the ring. The magnets are coupled with the ring such that the ring may be compressed and expanded with the magnets secured in the ring.

US Patent:

6798109, Sep 28, 2004

Filed:

Oct 31, 2002

Appl. No.:

10/286111

Inventors:

Earl M. Ortt - Bel Air MD
Robert J. Marcinkowski - Cockeysville MD
Michael J. Agnes - Bel Air MD
Mark D. Williams - Hampstead MD

Assignee:

Black Decker Inc. - Newark DE

International Classification:

H02K 1300

US Classification:

310239, 310242

Abstract:

An electrically conductive brush box is located against the upper surface of a base and has crimping tabs located against an oppositely disposed crimping surface. The base is formed of high temperature resistant plastic. A field case housing has a seat with a retention member adapted to retain the base against the seat. A screw is threaded into the field case housing such that the head presses against a surface of the base member to retain the base member in the seat. The screw member is located in non-contacting relationship with the electrically conductive brush box. A spacer member is adapted to space the portion of the crimping tab against the crimping surface away from the field case housing. The brush box includes a biasing member holder and the crimping tabs are located adjacent the holder.

US Patent:

7126242, Oct 24, 2006

Filed:

Apr 29, 2005

Appl. No.:

11/118918

Inventors:

Robert B. Williams - Baltimore MD, US
Robert J. Marcinkowski - Cockeysville MD, US
Earl M. Ortt - Bel Air MD, US
Bradley J. Mealy - Abingdon MD, US

Assignee:

Black & Decker Inc. - Newark DE

International Classification:

H02K 5/00

US Classification:

310 89, 310239

Abstract:

A field case housing has a substantially cylindrical wall segment, an end segment and a flange all having a substantially constant wall thickness. The flange has reinforcing ribs connected to the wall segment and aperture reinforcing bosses. The end segment, the wall segment and the flange are formed as a single, integral part adapted to reduce warping of the housing during molding. A cylindrical guide member is located in the field case housing and a conical guide member is located in the fan baffle. The cylindrical guide member is adapted to insure a screw passing through the cylindrical guide member is guided to a point within the conical guide member. The fan baffle has a transverse wall with an aperture and guide walls extending adjacent the aperture. The guide walls are adapted to guide an armature past the magnets without contacting and damaging them.

US Patent:

7135796, Nov 14, 2006

Filed:

Apr 29, 2005

Appl. No.:

11/119454

Inventors:

Earl M Ortt - Bel Air MD, US
Robert J Marcinkowski - Cockeysville MD, US
Michael J Agnes - Bel Air MD, US
Mark D Williams - Hampstead MD, US

Assignee:

Black & Decker Inc. - Newark DE

International Classification:

H02K 5/00
H02K 13/00

US Classification:

310 89, 310239

Abstract:

An electrically conductive brush box is located against the upper surface of a base and has crimping tabs located against an oppositely disposed crimping surface. The base is formed of high temperature resistant plastic. A field case housing has a seat with a retention member adapted to retain the base against the seat. A screw is threaded into the field case housing such that the head presses against a surface of the base member to retain the base member in the seat. The screw member is located in non-contacting relationship with the electrically conductive brush box. A spacer member is adapted to space the portion of the crimping tab against the crimping surface away from the field case housing. The brush box includes a biasing member holder and the crimping tabs are located adjacent the holder.

US Patent:

7799448, Sep 21, 2010

Filed:

Jun 16, 2008

Appl. No.:

12/213159

Inventors:

Nathan J. Cruise - Phoenix MD, US
Daniel J. White - Baltimore MD, US
Robert J. Marcinkowski - Cockeysville MD, US
Geoffrey S. Howard - Columbia MD, US
Alexis W. Johnson - Warren PA, US
Nathan J. Osborne - Baltimore MD, US
Steven J. Phillips - Ellicott City MD, US
Michelle L. Bowers - Westminster MD, US

Assignee:

Black & Decker Inc. - Newark DE

International Classification:

H01M 14/00
H01M 2/02
H02H 9/00
H02H 3/20

US Classification:

429 7, 361 56, 361118, 429163, 429178

Abstract:

A battery pack including a housing, a terminal block, a printed circuit board electrically connected to the terminal block, at least one battery cell, and a spark gap device on the printed circuit board to provide electrostatic discharge protection and disposed between the printed circuit board and the terminal block.
