Roger R Sanger

US Patent:

7056013, Jun 6, 2006

Filed:

Mar 31, 2004

Appl. No.:

10/813706

Inventors:

Peter Anderson - Georgetown, CA
Roger R. Sanger - Fountain Valley CA, US
Timothy J. Lippold - Huntington Beach CA, US
Paul J. Cairns - Huntington Beach CA, US

Assignee:

Honeywell International Inc. - Morristown NJ

International Classification:

G01K 1/16
G01K 13/02

US Classification:

374138, 374148, 374208

Abstract:

A temperature sensor arrangement () includes a sensor cavity (), a temperature sensing element () being positioned along a center line () of the sensor cavity () and generating a signal indicating temperature of air flowing thereto, and a generally cylindrical outer casing () surrounding the sensor cavity (). In one embodiment, the outer casing () includes a pattern of flow passages () for allowing air flow to the temperature sensing element () in the sensor cavity (), the flow passages () being angled such that there is no direct line of air flow from an exterior of the outer casing () to the sensing element (). In another embodiment, the flow passages () are arranged in an offset pattern relative to a center line () of the housing cavity (), such that there is no direct line of air flow from an exterior of the outer casing () to the sensing element ().

US Patent:

60704187, Jun 6, 2000

Filed:

Dec 23, 1997

Appl. No.:

8/996742

Inventors:

Ronald E Crabtree - Sun Lakes AZ
Peter C. Collins - Redondo Beach CA
Stanley C. Pollitt - Rancho Palos Verdes CA
Roger R. Sanger - Fountain Valley CA
Michel A. Jonqueres - Torrance CA
Thomas J. Kazan - Irvine CA

Assignee:

AlliedSignal Inc. - Morristown NJ

International Classification:

F25B 910

US Classification:

62 86

Abstract:

An environmental control system includes a single heat exchanger, a single water separator and two air cycle machines on separate spools. Cooling turbines of the air cycle machines are cascaded. Air flows through both air cycle machines during normal operation of the environmental control system. If one of the air cycle machines fails, air can be bypassed around the failed air cycle machine. Cascading allows water separation to be performed by a mid-pressure water separator located between the air cycle machines.

US Patent:

61486221, Nov 21, 2000

Filed:

Mar 23, 1999

Appl. No.:

9/274934

Inventors:

Roger Reed Sanger - Fountain Valley CA

Assignee:

AlliedSignal Inc. - Morristown NJ

International Classification:

F25B 900

US Classification:

62 88

Abstract:
