Ronald O Majors

US Patent:

D3504700, Sep 13, 1994

Filed:

Feb 11, 1993

Appl. No.:

D/004673

Inventors:

Ronald O. Majors - Salem WI
Joseph R. Hoepfl - Greenfield WI

Assignee:

Snap-On Incorporated - Kenosha WI

US Classification:

D 8 80

US Patent:

D3564819, Mar 21, 1995

Filed:

Feb 11, 1993

Appl. No.:

D/004668

Inventors:

Ronald O. Majors - Kenosha WI
Joseph R. Hoepfl - Greenfield WI

Assignee:

Snap-on Incorporated - Kenosha WI

US Classification:

D 8 80

US Patent:

52617149, Nov 16, 1993

Filed:

Apr 29, 1992

Appl. No.:

7/875342

Inventors:

Randall J. Slusar - Greenfield WI
Ronald O. Majors - Kenosha WI
Jeffrey R. Annis - Waukesha WI

International Classification:

B25J 1506

US Classification:

294 655

Abstract:

A magnetic pickup tool includes an elongated, flexible, tubular, conductive shaft connected to a handle at one end and to an electromagnet at the other end. The handle is an electrically conductive tube housing batteries and a push-button switch for connecting one battery terminal to the housing, the other battery terminal being connected to an insulated conductor which runs through the shaft for connection to one terminal of the electromagnet, which is provided with telescoping inner and outer pole pieces. A first tubular metal coupler electrically connects the handle to the shaft. A second metal tubular coupler has a diametrically slotted end which is received telescopically between the electromagnet pole pieces in contact with each, the electromagnet coil terminals being accommodated in the slot, the other end of the connector telescopically receiving the adjacent end of the shaft in contact therewith. A conductive potting connects the other terminal of the electromagnet to the tubular connector, while insulating potting fills the remainder of the slot and insulates the wire conductor and the one terminal of the electromagnet from the pole pieces and from the tubular connector.

US Patent:

D3502694, Sep 6, 1994

Filed:

Jan 12, 1993

Appl. No.:

D/003001

Inventors:

Ronald O. Majors - Kenosha WI
Joseph R. Hoepfl - Greenfield WI

Assignee:

Snap-on Tools Corporation - Kenosha WI

US Classification:

D 8 77
