Womply
Principal Software Engineer
Stubhub Apr 2016 - Mar 2016
Senior Mts Software Engineer
Ebay Oct 2013 - Dec 2014
Principal Software Engineer
Ebay Jun 2011 - Sep 2013
Mts 1 Software Engineer
Ptc Oct 2008 - Jun 2011
Technician Leader
Education:
Fudan University 1997 - 2001
Bachelors, Mathematics
Skills:
Scrum Java Enterprise Edition Java Agile Methodologies Spring Soa Architectures Hibernate Maven Web Services Spring Framework Xml Linux Ant Javascript Hadoop Distributed Systems Esb Scalability Eclipse Oracle Representational State Transfer Tomcat Activemq Design Patterns Object Oriented Design Zookeeper Kafka Solr Cloud Machine Learning Google Cloud Platform Pivotal Cloud Foundry Spring Boot Spring Cloud Software Architecture Elasticsearch Apache Spark Amazon Web Services Microservices Docker Kubernetes
Fei Yu - Santa Clara CA, US Anwar A. Mohammed - San Jose CA, US Rui Niu - Sunnyvale CA, US
Assignee:
FutureWei Technologies, Inc. - Plano TX
International Classification:
H05K 1/09 H05K 1/00 H05K 1/16 H05K 3/46 H05K 3/00
US Classification:
174257, 427 972, 29829, 174260, 174258
Abstract:
A structure for a core layer of a substrate and a method for fabricating a core layer of a substrate are disclosed. The core layer comprises a molding compound encapsulating a die or a plurality of dies, a dielectric layer on the surfaces of the molding compound, and a conductive layer on top of the dielectric layer. A through hole is formed through the dielectric layer and the molding compound, which may be filled with a metal plate. A laser via is formed similarly. Build-up layers may be assembled next to the core layer to form the substrate, which can be used to package dies.
Weifeng Liu - Dublin CA, US Rui Niu - Cupertino CA, US
International Classification:
H01L 23/498 H01L 23/48
US Classification:
257737, 257773
Abstract:
Polyimide-based redistribution layers (RDLs) can be employed to reduce thermo-mechanical stress that is exerted on conductive interconnections bonded to interposers in 2.5 D semiconductor packaging configurations. The polyimide-based RDL is located on an upper or lower face of an interposer. Additionally, height differentials between laterally adjacent semiconductor dies in 2.5 D semiconductor packages can be reduced or eliminated by using different diameter micro-bumps, different height copper pillars, or a multi-tiered interposer to lower taller semiconductor dies in relation to shorter semiconductor dies.
Large Sized Silicon Interposers Overcoming The Reticle Area Limitations
Haoyu Song - Cupertino CA, US Cao Wei - Cupertino CA, US Rui Niu - Cupertino CA, US Anwar A. Mohammed - San Jose CA, US
Assignee:
Futurewei Technologies, Inc. - Plano TX
International Classification:
H01L 23/48
US Classification:
257774, 257700
Abstract:
A multi-die integrated circuit assembly includes an interposer substrate larger than the typical reticle size used in fabricating the “active area” in which the through-silicon vias (TSVs) and interconnect conductors are formed in the interposer. At the same time, each of the dies has its external power/ground and I/O signal line connections concentrated into a smaller area of the die. The dies are disposed or mounted on the interposer such that these smaller areas (with the power/ground/IO connections) overlap with the active area of the interposer. In this configuration, a plurality of dies having a combined area substantially greater than the active area of the interposer can be mounted on the interposer (and take advantage of the active area for interconnections).
