Russell R Ellersick

US Patent:

46305947, Dec 23, 1986

Filed:

Feb 6, 1985

Appl. No.:

6/698613

Inventors:

Russell R. Ellersick - Roseville CA

International Classification:

F24C 1508

US Classification:

126 64

Abstract:

An infrared ray reflective coating for application to insulative materials comprising aluminum particles in an aqueous acidic binder slurry, a hardener, and a coating cement having about 96% of a mixture of Al. sub. 2 O. sub. 3 and SiO. sub. 2.

US Patent:

D2659344, Aug 24, 1982

Filed:

Aug 17, 1978

Appl. No.:

5/934637

Inventors:

Russell R. Ellersick - Citrus Heights CA

International Classification:

D2605
D2303

US Classification:

D26118

US Patent:

D2822024, Jan 14, 1986

Filed:

Apr 18, 1983

Appl. No.:

6/485862

Inventors:

Russell R. Ellersick - Citrus Heights CA

US Classification:

D23 77

US Patent:

43497241, Sep 14, 1982

Filed:

Nov 7, 1980

Appl. No.:

6/204760

Inventors:

Russell Ellersick - Citrus Heights CA

International Classification:

H05B 100

US Classification:

219347

Abstract:

A radiant heater modules comprises a plurality of quartz iodide bulbs projecting from an air cooled housing and a reflector to direct heat from the bulbs toward the pipe. This housing is of a generally box-like configuration and includes a top cover plate. The bulbs are mounted in sockets which are attached to the bottom side of the top cover plate and the sockets are electrically connected to a plug which is fixedly attached to the top side of the top cover plate. Means are also provided for rigidly securing the housing to the reflector.

US Patent:

41594118, Jun 26, 1979

Filed:

Sep 13, 1976

Appl. No.:

5/722791

Inventors:

Russell R. Ellersick - Citrus Heights CA

International Classification:

H05B 100
F21V 2900

US Classification:

219346

Abstract:

A portable radiant heating apparatus includes a pair of linearly extending members pivotally attached to one another adjacent a first end thereof and pivotal about the pivotal attachment to be generally parallel to one another. A lamp receiving electrical socket supported on the other end of each of the members receives a high intensity infrared lamp electrically arranged to receive power from its socket via means for connecting each of the sockets to an electrical power source. A concave infrared reflective shield is provided about each of the lamps and shaped to direct the light from each of the lamps generally uni-directionally. Thermal insulation means are also provided to protect the members and shields from the heat generated by the lamps.
