Russell Glenn Swaffar

US Patent:

20060045748, Mar 2, 2006

Filed:

Aug 30, 2004

Appl. No.:

10/930407

Inventors:

Christopher Cahoon - Mesa AZ, US
Russell Swaffar - Mesa AZ, US
Randall Dowding - Gilbert AZ, US

International Classification:

B64C 27/46

US Classification:

41622300R

Abstract:

The present invention provides an apparatus for use in automated welding repairs, particularly those repairs intended for impellers, blisks, and similar structures. There is provided a welding shield which is shaped to fit securely within valleys of an impeller. An individual shield is sized to match with a particular impeller design. When in place, the shield covers exposed areas of the valley and thus protects that area from welding damage. The shield may include welding resistant materials on exposed surfaces. A plurality of shields can protect as many impeller valleys as needed. The shield fits securely so that it does not dislodge during automated welding operations. If desired shields can be moved and repositioned so as to expose previously protected areas thus allowing welding to take place in the newly exposed areas.
