Ryo Fuchinoue

US Patent:

7845340, Dec 7, 2010

Filed:

Dec 17, 2007

Appl. No.:

12/002403

Inventors:

Ryo Fuchinoue - Greensburg IN, US
Catherine W. Dippold - Columbus IN, US

Assignee:

Cummins Inc. - Columbus IN

International Classification:

F02B 47/08
F02M 25/07

US Classification:

12356817, 12356811, 606052

Abstract:

One embodiment is an apparatus including an air-exhaust mixing passageway, a first lip extending into the passageway, a second lip extending into the passageway, a valley intermediate the first lip and the second lip, and an exhaust inlet aperture in flow communication with the flow channel.

US Patent:

7861580, Jan 4, 2011

Filed:

Jun 23, 2008

Appl. No.:

12/144494

Inventors:

Vivek A. Sujan - Columbus IN, US
Adrian P. Dale - Columbus IN, US
Jeffrey Matthews - Columbus IN, US
Kent Krajewski - Columbus IN, US
David Stroh - Columbus IN, US
Ryo Fuchinoue - Greensburg IN, US

Assignee:

Cummins IP, Inc. - Minneapolis MN

International Classification:

G01M 15/04

US Classification:

7311477

Abstract:

According to one exemplary embodiment, a virtual turbine speed sensor for a multi-stage turbocharger system of an internal combustion engine is disclosed. The multi-stage turbocharger system includes at least two sequential turbochargers each having a compressor and a turbine. The virtual turbine speed sensor includes a compressor efficiency module, an inter-stage air temperature module, and a turbine speed module. The compressor efficiency module is configured to estimate an efficiency of a compressor of a first of the at least two turbochargers. The inter-stage air temperature module is configured to estimate an inter-stage temperature of air between the at least two compressors. The inter-stage temperature estimate is based at least partially on the efficiency of the compressor of the first turbocharger. The turbine speed module is configured to estimate a speed of a turbine of a second of the at least two turbochargers. The speed estimate of the turbine of the second turbocharger is based at least partially on the temperature estimate of air between the at least two compressors.

US Patent:

20030230290, Dec 18, 2003

Filed:

Jun 13, 2002

Appl. No.:

10/170527

Inventors:

Jason Mackey - Taylorsville IN, US
Ryo Fuchinoue - Columbus IN, US

International Classification:

F02M025/07

US Classification:

123/568130, 123/568120

Abstract:

The present invention relates to an internal combustion engine cylinder head having an exhaust gas recirculation passage formed therein. The exhaust gas recirculation passage extending along the length of the cylinder head casting and disposed in a heat transfer relationship with a water jacket located within the cylinder head. One form of the present invention includes heat transfer members within the passage to increase the heat transfer between the exhaust gas flowing in the passage and the cylinder head.
