Saif E Khalil

US Patent:

8639484, Jan 28, 2014

Filed:

May 14, 2004

Appl. No.:

10/540968

Inventors:

Wei Sun - Cherry Hill NJ, US
Jae Hyun Nam - Broomall PA, US
Andrew Leete Darling - Philadelphia PA, US
Saif Khalil - King of Prussia PA, US

Assignee:

Drexel University - Philadelphia PA

International Classification:

G06G 7/48

US Classification:

703 11

Abstract:

A process and apparatus are provided for manufacturing complex parts and devices which utilize a CAD environment to design a part or device to be created (FIG. ); Boolean, scaling, smoothing, mirroring, or other operations to modify the CAD design; a software interface to convert the CAD designed part (Data Process System) or device into a heterogeneous material and multi-part assembly model (Design Input Model) which can be used for multi-nozzle printing; and a multi-nozzle system to print the designed part or device using different, specialized nozzles (Tissue substitutes).

US Patent:

20210035154, Feb 4, 2021

Filed:

Oct 16, 2020

Appl. No.:

17/072885

Inventors:

- Brooklyn Park MN, US
Saif Khalil - Wayne PA, US
Miles Curtis - Philadelphia PA, US
Christopher Biele - King of Prussia PA, US
Daniel Fellmeth - Eagleville PA, US

International Classification:

G06Q 30/02
A61N 1/378
A61N 1/36
H02J 50/90
H02J 50/70
H02J 50/12

Abstract:

A wireless charger system for inductively charging a rechargeable battery of an implantable pulse generator (IPG) implanted in a human body is provided. A charging coil in the charger is wirelessly coupled to a receiving coil of the IPG to charge the rechargeable battery. An end-of-charge (EOC) circuit continuously monitors the reflected impedance from a reflected impedance sensor and determines the end of charge when a predetermined pattern of the reflected impedance corresponding to an EOC signal from the IPG is received.Advantageously, receiving the EOC signal through the charging coil eliminates the need to provide a separate communication circuit in the IPG that communicates with the charger.

US Patent:

20200206509, Jul 2, 2020

Filed:

Mar 9, 2020

Appl. No.:

16/813680

Inventors:

- Brooklyn Park MN, US
Raghavendra Angara - West Chester PA, US
Saif Khalil - Wayne PA, US

International Classification:

A61N 1/36
A61N 1/378
A61N 1/05
A61N 1/02

Abstract:

An implantable pulse generator (IPG) that generates spinal cord stimulation signals for a human body has a programmable signal generator that can generate the signals based on stored signal parameters without any intervention from a processor that controls the overall operation of the IPG. While the signal generator is generating the signals the processor can be in a standby mode to substantially save battery power.

US Patent:

20200108258, Apr 9, 2020

Filed:

Sep 17, 2019

Appl. No.:

16/574025

Inventors:

- Brooklyn Park MN, US
Miles Curtis - Philadelphia PA, US
Christopher Biele - King of Prussia PA, US
Saif Khalil - Wayne PA, US
Jason Highsmith - Charleston SC, US

International Classification:

A61N 1/372
A61N 1/05
A61N 1/36

Abstract:

Systems, devices and methods for providing neuromodulation are provided. One such system can include an implantable pulse generator. The implantable pulse generator can include a circuit board having a microcontroller that generates signals that are input into an ASIC. The ASIC serves as pulse generator that allows electrical pulses to be outputted into leads. The implantable pulse generator is capable of receiving and/or generating signals either via a wireless communication (e.g., a wireless remote control), a touching force (e.g., pressure from a finger), a motion sensor or any combination of the above.

US Patent:

20190273404, Sep 5, 2019

Filed:

Feb 4, 2019

Appl. No.:

16/267354

Inventors:

- Brooklyn Park MN, US
Saif Khalil - Wayne PA, US
Miles Curtis - Philadelphia PA, US
Christopher Biele - King of Prussia PA, US
Daniel Fellmeth - Eagleville PA, US

International Classification:

H02J 50/70
A61N 1/36
A61N 1/378
H02J 50/12
H02J 50/90
H02J 7/02

Abstract:

A wireless charger for automatically tuning an optimum frequency to inductively charge a rechargeable battery of an implantable pulse generator (IPG) that generates spinal cord stimulation signals for a human body is provided. The charging coil in the charger is wirelessly coupled to a receiving coil of the IPG to charge the rechargeable battery. An optimization circuit detects a reflected impedance of the charging coil through a reflected impedance sensor, and select an optimum frequency of a charging signal supplied to the charging coil based on the detected reflected impedances of a plurality of charging frequencies in a selected frequency range. Advantageously, the optimum charging frequency provides a more efficient way to charge the IPG's rechargeable battery.

US Patent:

20190046805, Feb 14, 2019

Filed:

Oct 15, 2018

Appl. No.:

16/160994

Inventors:

- Brooklyn Park MN, US
Miles Curtis - Philadelphia PA, US
Christopher Biele - King of Prussia PA, US
Saif Khalil - Wayne PA, US
Jason Highsmith - Charleston SC, US

International Classification:

A61N 1/372
A61N 1/36
A61N 1/05

Abstract:

Systems, devices and methods for providing neuromodulation are provided. One such system can include an implantable pulse generator. The implantable pulse generator can include a circuit board having a microcontroller that generates signals that are input into an ASIC. The ASIC serves as pulse generator that allows electrical pulses to be outputted into leads. The implantable pulse generator is capable of receiving and/or generating signals either via a wireless communication (e.g., a wireless remote control), a touching force (e.g., pressure from a finger), a motion sensor or any combination of the above.

US Patent:

20180289961, Oct 11, 2018

Filed:

Jun 8, 2018

Appl. No.:

16/003235

Inventors:

- AUDUBON PA, US
Raghavendra Angara - West Chester PA, US
Saif Khalil - Wayne PA, US

International Classification:

A61N 1/36
A61N 1/378
A61N 1/05
A61N 1/02
A61N 1/372
A61N 1/375

Abstract:

An implantable pulse generator (IPG) that generates spinal cord stimulation signals for a human body has a programmable signal generator that can generate the signals based on stored signal parameters without any intervention from a processor that controls the overall operation of the IPG. While the signal generator is generating the signals the processor can be in a standby mode to substantially save battery power.

US Patent:

20180123380, May 3, 2018

Filed:

Dec 22, 2017

Appl. No.:

15/851837

Inventors:

- Audubon PA, US
Saif Khalil - Wayne PA, US
Miles Curtis - Philadelphia PA, US
Christopher Biele - King of Prussia PA, US
Daniel Fellmeth - Eagleville PA, US

International Classification:

H02J 7/02
A61N 1/378
A61N 1/36
A61N 1/02
A61N 1/05
A61N 1/372
A61N 1/375

Abstract:

A wireless charger for automatically tuning an optimum frequency to inductively charge a rechargeable battery of an implantable pulse generator (IPG) that generates spinal cord stimulation signals for a human body is provided. The charging coil in the charger is wirelessly coupled to a receiving coil of the IPG to charge the rechargeable battery. An optimization circuit detects a reflected impedance of the charging coil through a reflected impedance sensor, and select an optimum frequency of a charging signal supplied to the charging coil based on the detected reflected impedances of a plurality of charging frequencies in a selected frequency range. Advantageously, the optimum charging frequency provides a more efficient way to charge the IPG's rechargeable battery.
