Steven A Fantl

US Patent:

6434981, Aug 20, 2002

Filed:

Mar 1, 2001

Appl. No.:

09/795846

Inventors:

Steven A. Fantl - Colgate WI
James L. Welch - Waukesha WI
Jesse A. Marcelle - Franklin WI
John W. Grosz - Waupun WI
Edward A. Raleigh - Waunakee WI

Assignee:

Master Lock Company - Milwaukee WI

International Classification:

E05B 3706

US Classification:

70 25, 70 56, 70313, 70314

Abstract:

A combination lock having a housing, a shackle, a dial, a pushbutton, and a lock assembly. The lock assembly is made of a group of rotating disks having windows that can be aligned to open the lock. When the dial is turned according to the combination of the lock, the windows become aligned so that the user can depress the pushbutton to release the shackle. The pushbutton travels in a direction that is perpendicular to the axis of rotation of the dial. When the shackle is locked again, the pushbutton returns to its original position. As the pushbutton travels back to its original position, portions of the lock assembly are turned so that the combination must be reentered in order to reopen the lock.

US Patent:

7856855, Dec 28, 2010

Filed:

Mar 23, 2007

Appl. No.:

11/690241

Inventors:

Steven A. Fantl - Colgate WI, US
Patrick Smith - Birmingham MI, US

Assignee:

Commando Lock Company, LLC - Troy MI

International Classification:

E05B 67/22

US Classification:

70 39, 70 38 A, 70 40

Abstract:

A lock assembly has a lock body and a shackle. The shackle has a leg. A locking element is disposed in the lock body. The locking element is selectively engageable to the shackle. A cam is disposed in the lock body. The cam has a lock position for moving the locking element to engage the shackle. There is also an unlocked position for moving the locking element to disengage the shackle. The cam has a shackle removal position for removing the shackle from the lock body. The leg has a shackle removal recess sized to receive the locking element sufficiently so as to permit movement of the cam to the shackle removal position. The cam is configured to displace the locking element into the shackle removal recess.

US Patent:

20040011093, Jan 22, 2004

Filed:

Nov 8, 2002

Appl. No.:

10/290917

Inventors:

Steven Fantl - Colgate WI, US

International Classification:

E05B067/06
G05G005/00
F16H057/00

US Classification:

070/03800A, 070/053000, 070/202000

Abstract:

A curved shackle gunlock for rendering a gun inoperative from accidental or unauthorized use and for deterring theft. The unique shape of the shackle is critical and will fit most firearms, specifically an automatic rifle. The thickness of the shackle provides maximum protection against destruction and violation. The gunlock can be inserted in the opening of a handgun through the breach and magazine well, through the revolver frame, through the loading port of a shotgun, or through the magazine well of a specialty gun.

US Patent:

20100269550, Oct 28, 2010

Filed:

Jul 13, 2010

Appl. No.:

12/835056

Inventors:

Steven A. FANTL - Colgate WI, US
Patrick SMITH - Birmingham MI, US

International Classification:

E05B 67/22

US Classification:

70 39

Abstract:

A lock assembly includes a lock body with a shackle. The shackle has a leg. A locking element is disposed in the lock body and is selectively engageable to the shackle. A cam is disposed in the lock body and includes a locked position, an unlocked position and a shackle removal position. The leg includes a shackle removal recess that only partially extends circumferentially about an outer peripheral surface disposed about a longitudinal axis of the leg and is sized to receive the first locking element sufficiently to permit movement of the cam to the shackle removal position. The shackle is rotatable in the unlocked position to expose the shackle removal recess to the locking element.

US Patent:

58393099, Nov 24, 1998

Filed:

Nov 25, 1997

Appl. No.:

8/978629

Inventors:

Steven Albert Fantl - Colgate WI
Robert Douglas Weis - New Berlin WI

Assignee:

Master Lock Company - Milwaukee WI

International Classification:

E05B 2704

US Classification:

70493

Abstract:

A holding device for padlocks having lock housings of different sizes. The holding device includes guides for positioning the padlocks so that a shell-plug assembly disposed within the lock housing is maintained at a prescribed location. The holding device is attached to a shearing apparatus for shearing assembly pins in the shell-plug assembly.

US Patent:

57351538, Apr 7, 1998

Filed:

Apr 14, 1997

Appl. No.:

8/834141

Inventors:

Robert Harold Hanneman - Wind Lake WI
James George Wagner - West Bend WI
Steven A. Fantl - Colgate WI

Assignee:

Master Lock Company - Milwaukee WI

International Classification:

E05B 2704

US Classification:

70493

Abstract:

A turnable lock operable with driver and tumbler pins when positioned by a key at a shear line in which shearable assembly pins are assembled in the lock and thereafter sheared to form such driver and tumbler pins for operation thereon. Each assembly pin is selectively weakened at a plurality of locations which correspond with notched depth heights of the family of keys capable of insertion in the keyhole. Such weakening is controlled so that pin shearing can be accomplished by application of rotational or linear forces applied to any part of the lock except the key. When linear forces are used the tumbler or plug may be indexed to employ a driver pin as a plug lock.

US Patent:

56972393, Dec 16, 1997

Filed:

Jul 19, 1996

Appl. No.:

8/684752

Inventors:

Robert Harold Hanneman - Wind Lake WI
James George Wagner - West Bend WI
Steven A. Fantl - Colgate WI

Assignee:

Master Lock Company - Milwaukee WI

International Classification:

E05B 2702

US Classification:

70493

Abstract:

A turnable lock operable with driver and tumbler pins when positioned by a key at a shear line in which shearable assembly pins are assembled in the lock and thereafter sheared to form such driver and tumbler pins for operation thereon. Each assembly pin is selectively weakened at a plurality of locations which correspond with notched depth heights of the family of keys capable of insertion in the keyhole. Such weakening is controlled so that pin shearing can be accomplished by application of rotational or linear forces applied to any part of the lock except the key. When linear forces are used the tumbler or plug may be indexed to employ a driver pin as a plug lock.

US Patent:

62637134, Jul 24, 2001

Filed:

Mar 3, 1999

Appl. No.:

9/261158

Inventors:

Steven Albert Fantl - Colgate WI

Assignee:

Master Lock Company - Milwaukee WI

International Classification:

E05B 2904

US Classification:

70492

Abstract:

A lock and a method for manufacturing the lock. The lock comprises a shell having an interior cavity, a plug received in the interior cavity rotatably and axially slidably therein and defining a keyway configured to receive a preselected key, and a tumbler insertable in the plug. The tumbler has a plug portion disposed at a first axial location within the plug and resiliently biased outwardly toward a locked radial position and associated with the keyway such that the preselected key inserted in the keyway locates the tumbler in an unlock position and a shell portion disposed at a second axial location in the shell wherein the second axial location is axially spaced from the first axial location. The shell, the plug and the tumblers are configured such that the tumblers are sheared between the plug and the shell when the plug and the shell are forced axially toward each other.
