Stuart J Boland

US Patent:

8573722, Nov 5, 2013

Filed:

Feb 11, 2011

Appl. No.:

13/025406

Inventors:

Casey E. Walker - Boulder CO, US
Stuart J. Boland - Denver CO, US
John R. O'Toole - Longmont CO, US
Larry M. Ernst - Longmont CO, US

Assignee:

InfoPrint Solutions Company, LLC - Boulder CO

International Classification:

B41J 29/38
B41J 29/393

US Classification:

347 6, 347 19

Abstract:

A method is disclosed. The method includes setting a desired flow rate for ink in an ink jet printer, measuring an actual flow rate of the ink, determining if the measured flow rate is equal to the desired flow rate and adjusting the flow rate if the measured flow rate is not equal to the desired flow rate.

US Patent:

20120139990, Jun 7, 2012

Filed:

Dec 2, 2010

Appl. No.:

12/959077

Inventors:

Casey E. Walker - Boulder CO, US
Stuart J. Boland - Denver CO, US

International Classification:

B41J 29/393
B41J 2/165

US Classification:

347 19, 347 30

Abstract:

A method is disclosed. The method includes monitoring a sensor for measured vacuum pressure within a print head, determining if the vacuum pressure measured at the sensor is less than a predetermined pressure threshold and indicating that the print head is ready to be decoupled from the maintenance station if the measured vacuum pressure is less than the predetermined pressure threshold.

US Patent:

20120139995, Jun 7, 2012

Filed:

Dec 2, 2010

Appl. No.:

12/959071

Inventors:

Casey E. Walker - Boulder CO, US
Scott R. Johnson - Erie CO, US
Stuart J. Boland - Denver CO, US

International Classification:

B41J 2/145
B41J 2/175

US Classification:

347 40, 347 85

Abstract:

A system is disclosed. The system includes a print engine having one or more ink jet print heads and ink lines coupled to provide ink to each of the print heads. The system also includes a fluid change manifold coupled to the ink lines to remove fluid from the print engine via the ink lines.

US Patent:

20120154482, Jun 21, 2012

Filed:

Dec 20, 2010

Appl. No.:

12/973309

Inventors:

Casey E. Walker - Boulder CO, US
Stuart J. Boland - Denver CO, US

International Classification:

B41J 2/165

US Classification:

347 22

Abstract:

A print head maintenance manifold assembly is disclosed. The maintenance manifold assembly includes a multitude of hoses and a manifold coupled to the hoses via fittings. The manifold includes a first set of fittings and small diameter hoses coupled to print heads at a first section of the manifold and a second set of fittings and hoses coupled to a vacuum source at a second section of the manifold.

US Patent:

20120285708, Nov 15, 2012

Filed:

May 10, 2012

Appl. No.:

13/468520

Inventors:

Carl R. Bildstein - Lafayette CO, US
Stuart J. Boland - Denver CO, US
Scott Johnson - Erie CO, US
Casey E. Walker - Boulder CO, US

International Classification:

A62C 3/00
A62C 37/36
A62C 2/04

US Classification:

169 46, 169 60

Abstract:

Fire control and containment for a production printing system that includes a dryer unit, an air intake fan, and an exhaust fan. A fire control and containment system includes an enclosure surrounding the dryer unit. The enclosure includes controllable doors, a temperature sensor, and an air pressure sensor in the enclosure. The fire containment and control system also includes a controller operable to detect a fire event based on changes in air pressure and air temperature in the enclosure detected by the air pressure and air temperature sensors. In response to detecting the fire event, the controller closes the doors of the enclosure to prevent the print medium from entering, controls the air intake fan and the exhaust fan to reduce the air pressure in the enclosure, and controls the dryer unit to reduce temperature in the enclosure to suppress fire.

US Patent:

20120287195, Nov 15, 2012

Filed:

May 10, 2012

Appl. No.:

13/468196

Inventors:

Stuart J. Boland - Denver CO, US
Scott Johnson - Erie CO, US
Constantino J. Tadiello - Fort Collins CO, US
Casey E. Walker - Boulder CO, US

International Classification:

B41J 29/38

US Classification:

347 16

Abstract:

Systems and methods for a dryer unit of a printer. In one embodiment, a dryer unit includes a light source having a plurality of lamps. The dryer unit further includes a controller that associates a target output power with each of the lamps of the light source. When in operation, the controller determines a speed of a printable medium that passes through the dryer unit. The controller is able to vary an intensity of light generated by the light source based on the speed of the printable medium by varying which of the lamps of the light source are energized to their target output power.

US Patent:

20120287196, Nov 15, 2012

Filed:

May 10, 2012

Appl. No.:

13/468460

Inventors:

Stuart J. Boland - Denver CO, US
Larry M. Ernst - Longmont CO, US
Scott Johnson - Erie CO, US
Casey E. Walker - Boulder CO, US

International Classification:

B41J 29/38

US Classification:

347 16

Abstract:

Embodiments described herein provide variable heat control for a printer. One system includes a dryer operable to dry ink applied to a print medium. The system also includes a controller communicatively coupled to the dryer and operable to filter a bitmap to provide variable heat control from the dryer to the applied ink according to the bitmap to attach the ink to the print medium. The print medium may be a continuous form print medium. In this regard, the controller maybe operable to determine a speed at which the continuous form print medium is moving, to generate a heat control signal operable to provide the variable heat control, and to delay transmission of the heat control signal based on the determined speed of the continuous form print medium until the ink applied to the continuous form print medium is within range of the dryer.

US Patent:

20120287215, Nov 15, 2012

Filed:

May 10, 2012

Appl. No.:

13/468190

Inventors:

Stuart J. Boland - Denver CO, US
Scott Johnson - Erie CO, US
Zhenbi Su - Spring TX, US
Casey E. Walker - Boulder CO, US

International Classification:

B41J 2/01
G02B 7/182

US Classification:

347102, 359871

Abstract:
