US Patent:

6523391, Feb 25, 2003

Filed:

Jun 8, 2001

Appl. No.:

09/877812

Inventors:

Kenneth A. Knox - Kearney MO
Ronald Jay Nelson - Platte City MO
Terry L. Bellmore - Kansas City MO
Gregory Lee Carlock - LaFayette GA

Assignee:

Variform Inc. - Kearney MO

International Classification:

G01N 1902

US Classification:

73 1206, 73 1201

Abstract:

A vertical impact testing apparatus comprises a rigid frame, an anvil connected to the frame, a dart positioned above the anvil, and a dropped-weight mechanism slidably connected to the frame. The frame is comprised of a vertical column, a base, and a guide rail. The vertical column extends for a sufficient distance to securely support a weight assembly through travel from various heights for testing a specimen. To facilitate downward travel of the dropped-weight mechanism at a proper vertical orientation, a guide block is rigidly attached to the weight assembly and the dropped-weight mechanism is slidably mounted to the guide rail. The dart is stabilized by a braced support arm connected to the frame and a bearing acting cooperatively to ensure impact of the dart with the specimen is in the vertical plane and without tilt. The anvil is a solid structure, fixed in position, which contacts and supports the specimen on a side opposite of the dart as the dart impacts the substrate and forces it downward.
