Thomas D Gore

US Patent:

7854221, Dec 21, 2010

Filed:

Aug 20, 2008

Appl. No.:

12/194615

Inventors:

Thomas D. Gore - South Lyon MI, US

International Classification:

F41B 11/00

US Classification:

124 63, 124 64, 124 65

Abstract:

A gas spring having an internal vibration damper for an air gun charging system. The gas spring including a relatively thin liner which is received within and abuts the elongated inner and/or outer wall of the tubular gas spring. The liner(s) absorbs vibration in the air gun to improve firing performance. A guide sleeve mounted to the outer surface of the gas spring abuts an air gun's tubular compression piston to transfer any vibrations in the compression piston to the liner. A tubular counter-weight is slidably mounted about the outer wall of the gas spring and strikes a forward end of the charging system after the air gun is fired to counter the post-firing recoil.

US Patent:

8132563, Mar 13, 2012

Filed:

Jul 24, 2009

Appl. No.:

12/509005

Inventors:

Thomas Gore - South Lyon MI, US

International Classification:

F41B 11/00

US Classification:

124 65

Abstract:

An air gun including a trigger assembly, a gas spring assembly, and a latch assembly is disclosed. The trigger assembly is moveable between an uncocked position and a cocked position. The gas spring assembly includes a compression cylinder and a piston moveable between an uncompressed position and a compressed position. Movement of the piston from the uncompressed position into the compressed position couples the latch assembly to the trigger assembly and the piston of the gas spring assembly. The latch assembly includes a locking portion that mechanically interlocks with a recess disposed on an interior surface of the piston to couple the latch assembly and the piston together. Actuation of the trigger assembly de-couples the latch assembly from the trigger assembly, permitting longitudinal movement of the latch assembly, which de-couples the latch assembly from the piston of the gas spring assembly.

US Patent:

8156929, Apr 17, 2012

Filed:

Nov 15, 2010

Appl. No.:

12/946300

Inventors:

Thomas D. Gore - South Lyon MI, US

International Classification:

F41B 11/00

US Classification:

124 63

Abstract:

A damper for an air gun has a gas spring at least partially disposed within a compression tube. The damper includes a damping component contacting the gas spring and the compression tube. The damping component damps vibrations in the air gun when the gun is fired.

US Patent:

8375930, Feb 19, 2013

Filed:

Nov 13, 2009

Appl. No.:

12/618301

Inventors:

Thomas Gore - South Lyon MI, US

International Classification:

F41B 11/00

US Classification:

124 66, 124 64, 124 65, 124 68

Abstract:

A vibration dampening system for an air gun charging system includes a rear guide tube and a forward guide tube that are received within opposite ends of an air gun power spring, and a sleeve that fits concentrically over the power spring. The rear guide tube and the sleeve cooperate to reduce the free length of the power spring allowed to vibrate, which reduces vibration and improves firing performance.

US Patent:

8397704, Mar 19, 2013

Filed:

Apr 17, 2012

Appl. No.:

13/448771

Inventors:

Thomas Gore - South Lyon MI, US

International Classification:

F41B 11/00

US Classification:

124 63

Abstract:

An assembly for an air gun that has a gas spring includes a sleeve contacting the gas spring. The sleeve may damp vibrations in the air gun when the gun is fired.

US Patent:

20100229844, Sep 16, 2010

Filed:

Mar 9, 2010

Appl. No.:

12/719888

Inventors:

Thomas Gore - South Lyon MI, US

International Classification:

F41B 11/34
F41B 11/00

US Classification:

124 80

Abstract:

A barrel break air gun includes a pair of opposed, generally planar faces defining a narrow gap between the breech and the barrel. The barrel face includes a circular groove concentric with the barrel bore that receives an annular seal, and a recessed annular land defined between the circular groove and the barrel bore. The annular seal may be either an o-ring nominally disposed within the circular groove, or an annular urethane washer that is slightly radially-compressed when placed into the circular groove such that the inner diameter of the washer projects slightly away from the barrel face prior to closing the barrel breech. In one embodiment featuring the annular washer, the washer's internal diameter is slightly smaller than the maximum skirt dimension of an air gun pellet, such that the pellet's skirt is retained by the washer upon closing the barrel breech.

US Patent:

55310397, Jul 2, 1996

Filed:

Mar 9, 1995

Appl. No.:

8/401240

Inventors:

Thomas D. Gore - Canton MI

International Classification:

F41G 1387

US Classification:

42101

Abstract:

A base for mounting an elongated telescopic sight on a gun which experiences a sudden reaction when a projectile is discharged from the gun. The gun has a pair of resilient leaf elements each supporting a sight mount to reduce the reactionary motion experienced by the sight.

US Patent:

55706762, Nov 5, 1996

Filed:

Mar 10, 1995

Appl. No.:

8/402471

Inventors:

Thomas D. Gore - Canton MI

International Classification:

F41B 1132
F41B 1116

US Classification:

124 56

Abstract:

This invention is related to a kit to retrofit a mechanically spring-powered air gun to a gas spring-powered air gun, and to a self-contained gas piston for an air gun. The gas piston has a center latch which engages the center latch operated by the trigger.
