Thomas Lee Meyer

US Patent:

20210244566, Aug 12, 2021

Filed:

Apr 28, 2021

Appl. No.:

17/242776

Inventors:

- Stevenage, GB
Benjamin L. Ko - Cincinnati OH, US
Robert H. Roth - Cincinnati OH, US
Mark S. Ortiz - Milford OH, US
Thomas E. Meyer - Philadelphia PA, US
Franklin S. Busch - South Bend IN, US
Isaac J. Khan - Bridgewater NJ, US
Michael F. Keane - Downingtown PA, US
Anna R. Raymond - Northwood OH, US
Jacob W. Schubert - Bellevue KY, US

International Classification:

A61F 9/00
A61F 9/013

Abstract:

An apparatus includes a body and a pair of rigid legs extending from the body. The body includes an engagement feature configured to engage a deployment instrument. The legs are parallel with each other. Each leg has a sharp tip. The legs both extend along a plane. The body defines a guide opening. The guide opening is oriented transversely relative to the plane associated with the legs. The guide opening is sized to receive a cannula having a generally flat profile. The guide opening is configured to guide the cannula through a sclerotomy at a substantially tangential orientation.

US Patent:

20210007890, Jan 14, 2021

Filed:

Sep 28, 2020

Appl. No.:

17/034707

Inventors:

- STEVENAGE, GB
Benjamin L. Ko - Cincinnati OH, US
Robert H. Roth - Cincinnati OH, US
Daniel J. Abbott - Maple Valley WA, US
Thomas E. Meyer - Philadelphia PA, US
Paul D. Gordon - Shreve OH, US

International Classification:

A61F 9/00
A61M 25/06
A61M 25/02

Abstract:

An apparatus includes a body, a needle, a catheter, and an actuator assembly. The needle extends distally from the body. The needle has an inner wall defining a needle lumen. The needle lumen is in fluid communication with a fluid port of the body. The catheter is slidably disposed in the needle lumen. The catheter has a catheter lumen. The first actuator assembly is configured to translate the catheter within and relative to the needle. The apparatus may also include an actuator assembly that is configured to rotate the needle relative to the body. The apparatus may be used to first deliver a leading bleb of fluid to the subretinal space in a patient's eye via the needle. The apparatus may then be used to deliver a therapeutic agent to the subretinal space in the patient's eye via the catheter.

US Patent:

20200297531, Sep 24, 2020

Filed:

Apr 29, 2020

Appl. No.:

16/861472

Inventors:

- Stevenage, GB
Brendan J. Oberkircher - Cincinnati OH, US
James G. Lee - Raynham MA, US
Clinton Denlinger - Cincinnati OH, US
Daniel J. Prenger - Loveland OH, US
Geoffrey King - Cincinnati OH, US
Scott Uhland - San Jose CA, US
Mark C. Tsai - Chalfont PA, US
Michael F. Keane - Downington PA, US
Isaac J. Khan - Bridgewater NJ, US
Benjamin L. Ko - Cincinnati OH, US
Thomas E. Meyer - Philadelphia PA, US
Denis P. Turner - San Clemente CA, US

International Classification:

A61F 9/00
A61M 25/02
A61B 50/30
A61B 46/23

Abstract:

An apparatus includes a pad assembly, an injector assembly, an injector driver, and a fluid source. The pad assembly is sized and configured to be placed on a forehead of a patient. The injector assembly includes a body, a flexible cannula, and a needle. The body is configured to be removably secured to the pad assembly. The cannula is sized to be inserted through an incision in an eye of a patient. The needle is slidably disposed in the cannula. The injector driver is operable to drive the needle longitudinally relative to the flexible cannula. The fluid source assembly is in fluid communication with the needle.

US Patent:

20180289540, Oct 11, 2018

Filed:

Mar 19, 2018

Appl. No.:

15/924395

Inventors:

- LONDON, GB
Thomas E. Meyer - Cincinnati OH, US
Daniel J. Abbott - Maple Valley WA, US
Michael F. Keane - Downingtown PA, US
Allen C. Ho - Lower Gwynedd PA, US
Mark C. Tsai - Chalfont PA, US
Isaac J. Khan - Bridgewater NJ, US

International Classification:

A61F 9/00
A61M 25/06

Abstract:

An apparatus has a first fluid conduit, a second fluid conduit, a connector member, an first tubular member, a second tubular member, and an inner cannula. The connector member has first and second passageways in which the first and second fluid conduits are positioned, respectively. A portion of the second tubular member is positioned within the lumen of the first tubular member. A proximal portion of the inner cannula is fixedly secured within the lumen of the first tubular member. The inner cannula lumen is in fluid communication with the first and second fluid conduits via the lumen of the first tubular member and the lumen of the second tubular member. The inner cannula may be inserted into the subretinal space of a human eye to deliver a leading bleb of fluid and then deliver a therapeutic agent, without having to withdraw the inner cannula from the subretinal space between the acts of delivering the leading bleb delivering the therapeutic agent.

US Patent:

20180263815, Sep 20, 2018

Filed:

Feb 15, 2018

Appl. No.:

15/897266

Inventors:

- LONDON, GB
Benjamin L. Ko - Cincinnati OH, US
Robert H. Roth - Cincinnati OH, US
Daniel J. Abbott - Maple Valley WA, US
Thomas E. Meyer - Cincinnati OH, US
Paul D. Gordon - Shreve OH, US

International Classification:

A61F 9/00
A61M 25/02
A61M 25/06
A61M 5/158

Abstract:

An apparatus includes a body, a needle, a catheter, and an actuator assembly. The needle extends distally from the body. The needle has an inner wall defining a needle lumen. The needle lumen is in fluid communication with a fluid port of the body. The catheter is slidably disposed in the needle lumen. The catheter has a catheter lumen. The first actuator assembly is configured to translate the catheter within and relative to the needle. The apparatus may also include an actuator assembly that is configured to rotate the needle relative to the body. The apparatus may be used to first deliver a leading bleb of fluid to the subretinal space in a patient's eye via the needle. The apparatus may then be used to deliver a therapeutic agent to the subretinal space in the patient's eye via the catheter.

US Patent:

20170360605, Dec 21, 2017

Filed:

May 31, 2017

Appl. No.:

15/609419

Inventors:

- Horsham PA, US
Benjamin L. Ko - Cincinnati OH, US
Robert H. Roth - Cincinnati OH, US
Mark S. Ortiz - Milford OH, US
Thomas E. Meyer - Cincinnati OH, US
Franklin S. Busch - South Bend IN, US
Isaac J. Khan - Bridgewater NJ, US
Michael F. Keane - Downingtown PA, US
Anna R. Raymond - Northwood OH, US
Jacob W. Schubert - Edgewood KY, US

International Classification:

A61F 9/00

Abstract:

An apparatus includes a body and a pair of rigid legs extending from the body. The body includes an engagement feature configured to engage a deployment instrument. The legs are parallel with each other. Each leg has a sharp tip. The legs both extend along a plane. The body defines a guide opening. The guide opening is oriented transversely relative to the plane associated with the legs. The guide opening is sized to receive a cannula having a generally flat profile. The guide opening is configured to guide the cannula through a sclerotomy at a substantially tangential orientation.

US Patent:

20170360606, Dec 21, 2017

Filed:

May 31, 2017

Appl. No.:

15/609457

Inventors:

- Horsham PA, US
Brendan J. Oberkircher - Cincinnati OH, US
James G. Lee - Cincinnati OH, US
Clinton Denlinger - Cincinnati OH, US
Daniel J. Prenger - Loveland OH, US
Geoffrey King - Cincinnati OH, US
Scott Uhland - San Jose CA, US
Mark C. Tsai - Chalfont PA, US
Michael F. Keane - Downington PA, US
Isaac J. Khan - Bridgewater NJ, US
Benjamin L. Ko - Cincinnati OH, US
Thomas E. Meyer - Cincinnati OH, US
Denis P. Turner - San Clemente CA, US

International Classification:

A61F 9/00

Abstract:

An apparatus includes a pad assembly, an injector assembly, an injector driver, and a fluid source. The pad assembly is sized and configured to be placed on a forehead of a patient. The injector assembly includes a body, a flexible cannula, and a needle. The body is configured to be removably secured to the pad assembly. The cannula is sized to be inserted through an incision in an eye of a patient. The needle is slidably disposed in the cannula. The injector driver is operable to drive the needle longitudinally relative to the flexible cannula. The fluid source assembly is in fluid communication with the needle.

US Patent:

20170360607, Dec 21, 2017

Filed:

May 31, 2017

Appl. No.:

15/609386

Inventors:

- Horsham PA, US
Brendan J. Oberkircher - Cincinnati OH, US
Daniel J. Prenger - Loveland OH, US
Geoffrey King - Cincinnati OH, US
Thomas E. Meyer - Cincinnati OH, US
Benjamin L. Ko - Cincinnati OH, US

International Classification:

A61F 9/007
A61F 9/00
A61M 5/24
A61B 17/34
A61M 5/20

Abstract:

An apparatus includes an injector, a first fluid conduit, a second fluid line, and a control module. The injector includes a body, a flexible cannula, a flexible needle, and a sensor. The needle is configured to translate relative to the cannula. The sensor is operable to detect a position of the needle relative to the cannula. The first and second fluid lines are coupled with the needle. The control module is in communication with the sensor, with the first fluid conduit, and with the second fluid conduit. The control module is configured to provide delivery of a first fluid through the first conduit to the needle based on a signal from the sensor. The control module is further configured to provide delivery of a second fluid through the second conduit to the needle.
