Vincent A Caluori

US Patent:

53496540, Sep 20, 1994

Filed:

Feb 20, 1992

Appl. No.:

7/839208

Inventors:

David G. Bond - Kent WA
Vincent A. Caluori - Kent WA
Todd Hill - Seattle WA
David T. Kirkland - Kent WA
Michael L. Raftery - Federal Way WA
Derek J. VanAlen - Kent WA

Assignee:

The Boeing Company - Seattle WA

International Classification:

G06F 1108

US Classification:

395575

Abstract:
