Walter J Bert

US Patent:

40761754, Feb 28, 1978

Filed:

Aug 24, 1976

Appl. No.:

5/717228

Inventors:

Walter J. Bert - McHenry IL

International Classification:

B05B 1302

US Classification:

239532

Abstract:

Industrial spraying apparatus for applying paint to an overhead pipe or the like that contains a pair of spaced apart contoured support members adapted to extend in surrounding relation to the pipe to be sprayed and having a passageway contained therein, with a nozzle mounted on each of the support members in communicating relation with the passageway and directed in the direction of the pipe so as to obtain an application of the paint onto the pipe. A paint supply is connected to each of the support members and communicating with each passageway, to provide a constant flow of paint to the nozzles. A mounting bracket is provided for pivotally connecting the support members and extension bracket connected to the mounting bracket at substantially one end thereof and adapted to receive interchangeable handles of various lengths so as to permit the user of the spraying apparatus to retain and move the support members relative to the pipe to be sprayed is also provided.
