Walter T Mayers

US Patent:

44794614, Oct 30, 1984

Filed:

Jul 15, 1982

Appl. No.:

6/398501

Inventors:

Mario J. Felice - Dearborn Heights MI
Walter T. Mayers - West Bloomfield MI

Assignee:

Ford Motor Company - Dearborn MI

International Classification:

F01L 100

US Classification:

123 9065

Abstract:

A vibration damper for a coil spring 16 includes a cylindrical shaped sleeve 18 which receives the coil spring 16 such that the outer portions 38 of the coils 36 slidably abut the inside surface of wall 20 of the sleeve 18 to provide frictional damping of the coil spring as it axially compresses and elongates.

US Patent:

45385637, Sep 3, 1985

Filed:

Sep 4, 1984

Appl. No.:

6/647125

Inventors:

Walter T. Mayers - West Bloomfield MI

Assignee:

Peterson American Corporation - Southfield MI

International Classification:

F01L 310

US Classification:

123 9067

Abstract:

An improved spring damper assembly is disclosed which comprises a helical coil spring having a generally cylindrically shaped sleeve member fitted thereto. The sleeve member has resilient sidewall portions which are designed to frictionally engage surfaces of the coil spring so as to dampen the oscillatory movement of the spring member whereby resonance of the spring is attenuated. The sleeve member includes a continuous integrally formed radially extending flange portion at one end thereof which overlies the end coil of the spring and operates to prevent excessive wear and/or gouging of the seating surface against which the spring is intended to bear due to rotational movement of the spring assembly during cyclic operation thereof.
