Wendell Walter Goodwin

US Patent:

20110017589, Jan 27, 2011

Filed:

Jul 23, 2010

Appl. No.:

12/842910

Inventors:

Wendell W. Goodwin - Walnut CA, US

International Classification:

C25B 9/02
B23P 19/10
C25B 11/00

US Classification:

2042861, 2952501, 20429701

Abstract:

An anode mount assembly is provided for facilitating rapid replacement of an anode component. The adapter mount assembly can comprise a mount component comprising a component body having at least one mounting aperture disposed therein and at least one protrusion or recess that can engage a recess or protrusion of the anode component for restricting movement of the anode component with respect to the mount component in at least one of a rotational and a translational direction of movement. Further, the anode component can comprise an engagement aperture, and the mounting aperture and the engagement aperture can be configured to receive a fastener for securing the anode component to the mount component and for restricting at least one additional degree of movement of the anode component with respect to the mount component to thereby secure the anode component to the mount component.

US Patent:

40777421, Mar 7, 1978

Filed:

Aug 23, 1976

Appl. No.:

5/716980

Inventors:

Wendell W. Goodwin - Lakewood CA

International Classification:

B63H 120

US Classification:

416245A

Abstract:

A protector kit for the outboard end of a marine propeller shaft including a reusable brass fastener sandwiched between a sacrificial anodic zinc nose piece and the end of the shaft. The brass fastener serves as a jam nut for the propeller and includes a deformable member and a set screw cooperating with one another to hold a propeller and the nose piece assembled to the shaft. The cup-shaped nose piece is formed solely of zinc and its internal threads hold it securely assembled to the brass fastener by an interference fit between the nose piece threads and the shallow inboard end of the brass fastener threads.

US Patent:

42807948, Jul 28, 1981

Filed:

Mar 19, 1979

Appl. No.:

6/021334

Inventors:

Wendell W. Goodwin - Lakewood CA

International Classification:

B63H 2334

US Classification:

416146R

Abstract:

A sacrificial anodic protector kit for propeller shafts comprising a split zinc collar having a copper layer on its interior surface. The collar is clampable about a propeller shaft by machine screws mateable with nuts embedded in the collar.

US Patent:

49150537, Apr 10, 1990

Filed:

Sep 9, 1988

Appl. No.:

7/242155

Inventors:

Wendell Goodwin - South El Monte CA

International Classification:

B63B 1700

US Classification:

114343

Abstract:

An improved sacrificial marine anode is adapted for installation on numerous different types of marine vessels. The anode is comprised of a plate of sacrificial metal formed with a pair of longitudinally aligned slots which are spatially separated from each other and which are defined entirely within the perimeter of the plate. The anode may be installed on a marine vessel having a hull and a pair of spatially separated studs projecting from the hull below the waterline thereof. The anode is installed by placing the slab against the hull from beneath the waterline such that the studs project through the slots, and securing fasteners to the ends of the studs to clamp the slab against the hull.
