William H Nold

US Patent:

45837970, Apr 22, 1986

Filed:

Jun 11, 1985

Appl. No.:

6/743500

Inventors:

Anthony R. Engelmore - Prospect KY
William H. Nold - Prospect KY

International Classification:

H01R 3500

US Classification:

339 6R

Abstract:

The low friction rotatable electrical connector is for use with a coiled telephone cord to prevent the cord from becoming twisted or tangled during use. This connector is generally of insulating material formed with a hollow housing for supporting a rotor assembly therein. This rotor assembly is a hollow cylinder that is positioned within the housing for relative rotation therein. One end wall of the housing has a circular opening in which one end of the rotor assembly is supported for rotation. The rotor assembly has a single longitudinal split for nearly the entire length thereof, but the split does not include the journal at one end that is located within the circular opening or bearing in the end wall of the housing. The rotor assembly supports a plurality of continuous conductive rings on the exterior thereof, and there is an insulating washer positioned between each pair of conductive rings to serve as a spacer between adjacent rings. Each conductive ring includes a separate insulated conductor on the underside that extends through the split in the rotor.

US Patent:

RE328057, Dec 20, 1988

Filed:

Nov 18, 1986

Appl. No.:

6/933560

Inventors:

Anthony R. Engelmore - Mechanicsburg PA
William H. Nold - Prospect KY

International Classification:

H01R 3500

US Classification:

439 26

Abstract:

The low friction rotatable electrical connector is for use with a coiled telephone cord to prevent the cord from becoming twisted or tangled during use. This connector is generally of insulating material formed with a hollow housing for supporting a rotor assembly therein. This rotor assembly is a hollow cylinder that is positioned within the housing for relative rotation therein. One end wall of the housing has a circular opening in which one end of the rotor assembly is supported for rotation. The rotor assembly has a single longitudinal split for nearly the entire length thereof, but the split does not include the journal at one end that is located within the circular opening or bearing in the end wall of the housing. The rotor assembly supports a plurality of continuous conductive rings on the exterior thereof, and there is an insulating washer positioned between each pair of conductive rings to serve as a spacer between adjacent rings. Each conductive ring includes a separate insulated conductor on the underside that extends through the split in the rotor.
