US Patent:

20100185961, Jul 22, 2010

Filed:

Jan 20, 2009

Appl. No.:

12/356084

Inventors:

Danyel Fisher - Seattle WA, US
Aaron Hoff - Kirkland WA, US
George Robertson - Northeast Harbor ME, US
Heather Warncke - Seattle WA, US
Mary Czerwinski - Kirkland WA, US
Albert Greenberg - Seattle WA, US
Dave Maltz - Bellevue WA, US
Xiaoyu Wang - Charlotte NC, US

Assignee:

Microsoft Corporation - Redmond WA

International Classification:

G06F 3/048
G06F 17/30
G06F 15/177

US Classification:

715760, 713 1, 707E17005, 707E17014

Abstract:

Techniques are described for generating a user interface for visualizing a cloud service based on status and performance data of the cloud service obtained from data stores. A configuration file including declarative code may declare particular queries to status/performance data sources. The configuration file may also declare particular queries to topology data sources to obtain topology information. In accordance with the obtained information, objects representing the cloud service may be displayed. The objects correspond to particular hardware and software components, or logical grouping thereof, that are identified by the topology information.
