David A Fernandez

US Patent:

46143416, Sep 30, 1986

Filed:

Jul 19, 1984

Appl. No.:

6/632453

Inventors:

David Fernandez - Camarillo CA

International Classification:

A63B 4910

US Classification:

273 73C

Abstract:

Improved tennis racket in which an inverted chevron shaped yoke is provided having downward sloping side portions which match the curvature of the arcuate top portion of the racket head to provide vertical strings extending between the yoke and arcuate top portion which are of the same length. The equal length of vertical strings provide uniform elastic response to ball impact. The particular design of the chevron provides added structural strength to the neck of the racket. An improved racket made from a polycrystalline metal oxide fiber and resin matrix is also disclosed. In addition, an improved string protection system involving elastomer inserts which are molded into the head portion of composite material rackets is described.

US Patent:

RE330116, Aug 8, 1989

Filed:

Feb 17, 1987

Appl. No.:

6/943560

Inventors:

David Fernandez - Camarillo CA

International Classification:

A63B 4910

US Classification:

273 73C

Abstract:

Improved tennis racket in which an inverted chevron shaped yoke is provided having downward sloping side portions which match the curvature of the arcuate top portion of the racket head to provide vertical strings extending between the yoke and arcuate top portion which are of the same length. The equal length of vertical strings provide uniform elastic response to ball impact. The particular design of the chevron provides added structural strength to the neck of the racket. An improved racket made from a polycrystalline metal oxide fiber and resin matrix is also disclosed. In addition, an improved string protection system involving elastomer inserts which are molded into the head portion of composite material rackets is described.

US Patent:

44363052, Mar 13, 1984

Filed:

Aug 26, 1981

Appl. No.:

6/296255

Inventors:

David Fernandez - Camarillo CA

Assignee:

American Sports Equipment - Camarillo CA

International Classification:

A63B 4902
A63B 4912

US Classification:

273 73C

Abstract:

A frame structure adapted for use as a tennis racket. The frame structure includes a frame body made from either wood, metal or plastic having a tubular structure with inside and outside surfaces. A composite material jacket having an outer layer adjacent and bonded to the frame outside surface and an inner layer adjacent and bonded to the frame body inside surface is provided. The composite material jacket is made from composite materials such as resin impregnated boron, graphite, polyamide aromatic and glass fibers. In addition, plastic throat pieces commonly used to connect and support racket necks and handles are replaced by composite material cross-member supports which are integrally molded to the composite material jacket. The composite material jacket provides structural reinforcement as well as desirable shock and vibration dampening characteristics. In addition, the tubular frame is provided with elongated slots through which racket strings are attached for mounting.

US Patent:

47936169, Dec 27, 1988

Filed:

Jan 21, 1987

Appl. No.:

7/006002

Inventors:

David Fernandez - Camarillo CA

International Classification:

A63B 5304

US Classification:

273167H

Abstract:

A golf club head including a lightweight composite material molded to a hard, high density material to provide selected distribution and localization of mass within the golf club head. The lightweight composite material provides desirable properties of strength and stiffness to the club head hosel and blade portions while the hard, high density material provides necessary club weight, mass distribution, structure and shape. The use of lightweight composite material in combination with high density material allows placement of the club mass substantially entirely in the blade or head portion to provide enhanced energy transfer. Club heads utilizing ceramic fiber and/or ceramic particles are also disclosed. The club head may include a central foam core surrounded by a rigid shell including resin impregnated fibers and ceramic particles dispersed in the resin.

US Patent:

44138229, Nov 8, 1983

Filed:

Jul 31, 1981

Appl. No.:

6/288999

Inventors:

David Fernandez - Camarillo CA
Helena J. Fernandez - Camarillo CA

Assignee:

American Sports Equipment - Camarillo CA

International Classification:

A63B 4910

US Classification:

273 73C

Abstract:

A tubular frame structure adapted for use as a tennis racket which includes an elastic polymer core which is bonded to and surrounded by a rigid shell of graphite composite. The elastic polymer core is a flexible vinyl foam prepared from plasticized polyvinyl chloride in which a suitable blowing agent is dispersed. A method for preparing the racket structure is disclosed. The elastic polymer core provides a particularly desirable core material which does not degrade or breakdown during prolonged use and provides enhanced racket shock and vibration absorption, and, most importantly, the means to obtain the desirable variable density characteristics at the desired locations within the structure of racquet without a corresponding reduction in structural capability.

US Patent:

D2897865, May 12, 1987

Filed:

Jul 19, 1984

Appl. No.:

6/632452

Inventors:

David Fernandez - Camarillo CA

US Classification:

D21212

US Patent:

43570135, Nov 2, 1982

Filed:

Jul 31, 1981

Appl. No.:

6/289038

Inventors:

David Fernandez - Camarillo CA
Francis Van Dyck - 4020 Liege, BE

International Classification:

A63B 4910

US Classification:

273 73C

Abstract:

A tubular frame structure adapted for use as a tennis racket having a rigid outer shell of composite material and an inner reinforced foam core including a foam portion and honeycomb reinforcement layers. The honeycomb reinforcement layers are oriented so that string holes passing through the frame pass through the foam core and rigid shell, but do not pass through the honeycomb layers. The use of honeycomb reinforcement layers is particularly well suited for use with elastic polymer foam cores.

US Patent:

20160061569, Mar 3, 2016

Filed:

Aug 27, 2014

Appl. No.:

14/470512

Inventors:

David Fryderyk Fernandez - Camarillo CA, US

International Classification:

F41H 5/04
F41H 5/013

Abstract:

Armor material, armor shields and other armor structures are composed of a continuous piece of material that is pressed and molded or otherwise processed to have two or more panels connected together at hinge portions, to form a foldable (or partially foldable) configuration. In a folded state the armor structure can provide a greater penetration stopping capability or NIJ rating, or both, as compared to an unfolded state. Such multi-panel armor structures are configured as foldable shields, walls, and enclosures.
