US Patent:

20150145286, May 28, 2015

Filed:

Nov 27, 2013

Appl. No.:

14/092368

Inventors:

- Detroit MI, US
Martin G. Foulkes - Howell MI, US
William P. Ciaramitaro - Sterling Heights MI, US
Jack E. Brown - Rochester Hills MI, US
Michael W. Davenport - Clarkston MI, US
Keith J. Saari - Macomb Township MI, US

Assignee:

GM GLOBAL TECHNOLOGY OPERATIONS LLC - Detroit MI

International Classification:

B62D 65/00
B22D 17/22
B22D 25/02
B62D 25/04
B62D 29/00

US Classification:

29619306, 298972, 295921

Abstract:

A hinge pillar assembly includes a hinge pillar panel that is cast from a die casting process, and that defines an interior surface. An acoustic foam layer is disposed adjacent the interior surface of the hinge pillar panel. An inner retainer panel is attached to the hinge pillar panel. The inner retainer panel secures the acoustic foam layer between the inner retainer panel and the hinge pillar panel. The hinge pillar assembly is cast to define a cored boss that is used to retain the hinge pillar panel within an upper ejector half of a die set during the casting process. A fastener is disposed in the threaded engagement with the cored boss to attach the inner retainer panel to the hinge pillar panel. A vehicle component may be attached to the inner retainer panel.
