Larry Thomas Nelson

US Patent:

40514404, Sep 27, 1977

Filed:

Mar 4, 1976

Appl. No.:

5/663663

Inventors:

Larry A. Nelson - Hillsboro OR
Philip Stephen Crosby - Beaverton OR

Assignee:

Tektronix, Inc. - Beaverton OR

International Classification:

H03B 304
H03D 1300
H03D 300
H03K 906

US Classification:

328134

Abstract:

A phase detector provides a voltage output which depends upon the phase difference between a limited input signal and a reference signal. The phase detector increases the dynamic range of the resultant phase locked loop. An embodiment which illustrates the capability of the design is a SECAM color difference signal demodulator.

US Patent:

39494179, Apr 6, 1976

Filed:

Sep 16, 1974

Appl. No.:

5/506381

Inventors:

Larry Allan Nelson - Hillsboro OR

Assignee:

Tektronix, Inc. - Beaverton OR

International Classification:

H04N 940
H04N 9535

US Classification:

358 14

Abstract:

A SECAM decoder for deriving the signals for a color display from the composite color picture signal determined largely by digital means having digital line switching, multiple delay lines, decoder center frequency clamps and indicator of drift of encoded white, dual digital phase detector for each phased locked loop decoder, switchable de-emphasis and a waveform squaring circuit whereby ease of adjustment to different recording subcarrier frequencies or to sequence color and memory standards is provided.

US Patent:

41919653, Mar 4, 1980

Filed:

Jul 11, 1978

Appl. No.:

5/923755

Inventors:

Larry A. Nelson - Hillsboro OR

Assignee:

Tektronix, Inc. - Beaverton OR

International Classification:

H04N 962

US Classification:

358 10

Abstract:

An apparatus and method for testing color sequencing of SECAM color television signals whereby any reversed color sequences will be immediately identifiable is provided. Specifically, the color sequence of SECAM picture monitor determined by white lead-in during the back porch interval or by Line Identification Signals during the vertical blanking interval is compared to a reference which can be internally derived and/or derived from another picture monitor or generator. If a difference is obtained, means are provided for visually or audibly indicating the color sequence error.

US Patent:

41515510, Apr 24, 1979

Filed:

Aug 4, 1976

Appl. No.:

5/711654

Inventors:

Larry A. Nelson - Hillsboro OR

Assignee:

Tektronix, Inc. - Beaverton OR

International Classification:

H04N 949

US Classification:

358 26

Abstract:

A programmable color enable and sequencing system for a sequential color and memory television system is provided. An output for sequencing the sequential colors of the SECAM system in a decoder and enabling color if chrominance is present is generated by statistically detecting the presence of color information and, using the same statistical detector, provides for synchronization of the color sequence circuits. The statistical detection uses FM information provided during the vertical interval and/or information contained in the color subcarrier of the composite SECAM signal. Additionally, the system includes means for providing a preprogrammed color enable for each one-half line defined according to user needs or system standards for enabling instantaneous decisions about which lines of the composite signal are color. Decisions as to whether or not the overall picture is color are made by the statistical detector.

US Patent:

41352017, Jan 16, 1979

Filed:

Mar 9, 1977

Appl. No.:

5/776066

Inventors:

Douglas P. Dickie - Portland OR
Larry A. Nelson - Hillsboro OR

Assignee:

Tektronix, Inc. - Beaverton OR

International Classification:

H04N 9537
H04N 950
H04N 514

US Classification:

358 40

Abstract:

A switching element is placed across a filter and controllably activated to dynamically change the response of the filter. Specifically, additional damping is switched into the "Bell" characteristic, interjected during blanking and removed after the beginning of white lead-in, to dynamically change the response of the band-pass "Bell" filter in a Sequential Color and Memory Television System.

US Patent:

39394328, Feb 17, 1976

Filed:

Mar 18, 1974

Appl. No.:

5/452298

Inventors:

Larry Allan Nelson - Hillsboro OR

Assignee:

Tektronix, Inc. - Beaverton OR

International Classification:

H03B 1900
H03K 500

US Classification:

328 13

Abstract:

A system for limiting an FM signal to produce outputs which are TTL compatible, yet retain the zero crossings of the incoming FM signal as long as the amplitude of that signal remains above a chosen minimum and the frequency remains less than a chosen amount.
