Michael W Flaherty

US Patent:

20210239539, Aug 5, 2021

Filed:

Sep 18, 2020

Appl. No.:

17/026094

Inventors:

- Norwood MA, US
Michael J. Flaherty - Halifax MA, US
Eugene Oh Hwang - Melrose MA, US

Assignee:

Analog Devices, Inc. - Norwood MA

International Classification:

G01K 1/18
G01K 1/02
G01K 1/08

Abstract:

Packages for wireless temperature sensor nodes are described. These wireless temperature sensor nodes are suitable for sensing the temperature of remote objects, such as objects that are difficult to access. These packages are designed to enhance the sensor's ability to sense temperature. For example, these packages may be designed to provide a low thermal resistance path between the object and the temperature sensor, a high thermal resistance between an antenna of the wireless temperature sensor node and the object, and at least in some embodiments, immunity to vibrations. One such package includes means for providing a thermal conductive path from the temperature sensor to a thermally conductive support in contact with the object (for example with a thermal resistance less than 10 K/W), and means for thermally conductively decoupling the circuit board from the thermally conductive support (for example by at least 100 K/W).
