Michael J Ulczynski

US Patent:

6409093, Jun 25, 2002

Filed:

Jan 15, 2001

Appl. No.:

09/761071

Inventors:

Michael J. Ulczynski - Riverview MI
Brian L. Wright - Mason MI
James Ray Miller - Williamston MI

Assignee:

Board of Trustees of Michigan State University - East Lansing MI

International Classification:

B05B 1700

US Classification:

239 1, 239 69, 239 70, 239373, 239584, 239600, 222399, 222646

Abstract:

An electronically controlled micro-dispensing apparatus ( ) is described. The apparatus includes a container ( ), an adaptor ( ), a nozzle ( ) and a control circuit ( or ). The container is filled with the chemical ( ) and propellant ( ). The adaptor, nozzle and control circuit are removable from the container and are reusable. The control circuits controls the length of pulse and the time duration between each pulse. By controlling these factors, the apparatus dispenses a precise amount of liquid over a set time period. The ejector allows for controlled dispensing and allows the liquid to be sprayed a greater distance. In the preferred embodiment, the apparatus are used to dispense a pheromone in an outdoor setting, such as an orchard ( ), to control insects.

US Patent:

61829048, Feb 6, 2001

Filed:

Oct 8, 1999

Appl. No.:

9/415509

Inventors:

Michael J. Ulczynski - Riverview MI
Brian L. Wright - Mason MI
James Ray Miller - Williamston MI

Assignee:

Board of Trustees operating Michigan State University - East Lansing MI

International Classification:

B05B 1700
A01G 2700

US Classification:

239 1

Abstract:

An electronically controlled micro-dispensing apparatus (10) is described. The apparatus includes a container (12), an adaptor (18), a nozzle (28) and a control circuit (34 or 42). The container is filled with the chemical (104) and propellant (102). The adaptor, nozzle and control circuit are removable from the container and are reusable. The control circuits controls the length of pulse and the time duration between each pulse. By controlling these factors, the apparatus dispenses a precise amount of liquid over a set time period. The ejector allows for controlled dispensing and allows the liquid to be sprayed a greater distance. In the preferred embodiment, the apparatus are used to dispense a pheromone in an outdoor setting, such as an orchard (100), to control insects.
