US Patent:

42637139, Apr 28, 1981

Filed:

Oct 16, 1978

Appl. No.:

5/951927

Inventors:

Edward H. Smith - Plum Borough PA
Richard L. Stiller - Natrona Heights PA
Robert Shaffer - Swissvale PA

Assignee:

Westinghouse Electric Corp. - Pittsburgh PA

International Classification:

B23P 1904

US Classification:

29727

Abstract:

An apparatus for actuating a tube guide expander device inserted in a tube end and extracting it therefrom subsequent to tube expansion induced by guide-expander actuation. The apparatus includes inner and outer sleeve structures which are independently axially displaceable relative to the tube and guide-expander. The outer sleeve structure is engageable with a first compression structure of the device to secure it and its engaged tube in place during relative axial displacement of a second compression structure of the device. Selectively coupling the inner sleeve structure to the device's second compression structure and axial displacement of both axially compresses a radial expansion element situated between the compression structures and expands the enclosing tube. A series of balls are radially displaceable from an outer unobstructing position through radial openings in the inner sleeve structure and an intermediate sleeve structure to an inner obstructing position protruding into the inner sleeve structure's bore so as to axially engage a portion of the second compression structure and prevent its extraction from the bore during axial displacement of the inner sleeve structure. Radial displacement of the balls is provided by selective axial displacement of the intermediate sleeve structure arranged about the inner sleeve structure.

US Patent:

47083247, Nov 24, 1987

Filed:

Feb 12, 1986

Appl. No.:

6/828818

Inventors:

Stanley R. Spiegelman - Pittsburgh PA
Phillip E. Miller - Greensburg PA
Robert Shaffer - Pittsburgh PA

Assignee:

Westinghouse Electric Corp. - Pittsburgh PA

International Classification:

C21D 900

US Classification:

266 87

Abstract:

Two sets of heater support members angularly distributed around a central vertical member are radially extendable individually or in groups to position heater elements within a preset distance of the cylindrical walls of any one of a series of pressure vessels having a range of diameters. A convex bottom heater support member is provided for each diameter vessel and is axially telescoped into the central vertical member so that an additional set of heater support members can be installed between the first mentioned two sets of heater support members and the bottom heater support member to accommodate for varying depths of the vessels in the series. Thermocouples are extended from the annealing device by actuators which use a spring or pneumatic pressure to press the thermocouple against the vessel wall with a preset constant force for accurate temperature measurements. The actuators use pneumatic pressure to retract the thermocouples to preclude damage during withdrawal of the annealing device from the vessel.

US Patent:

42199760, Sep 2, 1980

Filed:

Aug 1, 1978

Appl. No.:

5/930091

Inventors:

Robert D. Burack - Pittsburgh PA
Robert Shaffer - Swissvale PA

Assignee:

Westinghouse Electric Corp. - Pittsburgh PA

International Classification:

B24C 332
B24C 100

US Classification:

51411

Abstract:

The machine comprises a first assembly including a vertical post and a carriage track with a movable carriage thereon, the carriage track being pivotally secured to the upper end portion of the post so that the assembly can be collapsed to a size permitting entry into the channel head through a manway, with the assembly being sufficiently light in weight to permit its installation in the channel head by no more than two individuals, the machine further including a separate horizontal support beam and a separate curved track which are independently separably secured to the vertical post and to the outer end of the carriage track so that a generally quadrantally shaped frame is provided, the carriage track carrying an adjustable decontamination blaster means, and means are provided for moving the carriage along the carriage track and for swinging the carriage track both horizontally and vertically in the frame so that the decontamination means has the capability of sweeping past substantially all of the interiorly facing walls in the channel head. The method of carrying out the decontamination of all of the interiorly facing walls in the space in the channel head is accomplished by traversing the areas to be decontaminated by energizing selective drive means for successive sweeps at rates corresponding to the area to be traversed and then stepping the blaster means to different positions and varying the sweep rate in accordance with the different position.

US Patent:

42165695, Aug 12, 1980

Filed:

Nov 30, 1978

Appl. No.:

5/965016

Inventors:

Richard L. Stiller - St. Louis County MO
Robert Shaffer - Swissvale PA
Edward H. Smith - Plum Borough PA
Regis R. Vollmer - Trafford PA

Assignee:

Westinghouse Electric Corp. - Pittsburgh PA

International Classification:

B23P 1700

US Classification:

291573C

Abstract:

A method for inserting a tube through a tubesheet aperture and expanding it into contact with the aperture's wall. A tube guide-expander device is assembled in an open end of a tube with a portion of the device protruding from the tube. The guide-expander includes a distally protruding tip portion tapered to diverge in a direction toward the tube so as to facilitate insertion of the guide-expander and engaged tube through apertures in spatially separated tube supports and tubesheet. The guide-expander and tube engaged therewith are axially displaced relative to the tubesheet until the desired relative configuration is obtained. Expansion of the tube results from expanding the assembled tube guide-expander and driving the housing tube in the radial direction against the tubesheet aperture's wall. Such guide-expander expansion obtains from relatively axially displacing two structural components and compressing an interposed, radially expansible structure.

US Patent:

46027670, Jul 29, 1986

Filed:

Jun 22, 1984

Appl. No.:

6/623591

Inventors:

Stanley R. Spiegelman - Pittsburgh PA
Phillip E. Miller - Greensburg PA
Robert Shaffer - Pittsburgh PA

Assignee:

Westinghouse Electric Corp. - Pittsburgh PA

International Classification:

C21D 1100

US Classification:

266 87

Abstract:

Two sets of heater support members angularly distributed around a central vertical member are radially extendable individually or in groups to position heater elements within a preset distance of the cylindrical walls of any one of a series of pressure vessels having a range of diameters. A convex bottom heater support member is provided for each diameter vessel and is axially telescoped into the central vertical member so that an additional set of heater support members can be installed between the first mentioned two sets of heater support members and the bottom heater support member to accommodate for varying depths of the vessels in the series. Thermocouples are extended from the annealing device by actuators which use a spring or pneumatic pressure to press the thermocouple against the vessel wall with a preset constant force for accurate temperature measurements. The actuators use pneumatic pressure to retract the thermocouples to preclude damage during withdrawal of the annealing device from the vessel.
