Ryan M Rogers

US Patent:

20210293119, Sep 23, 2021

Filed:

Mar 18, 2020

Appl. No.:

16/822799

Inventors:

Ryan Rogers - Houston TX, US
Charles Meador - Cypress TX, US
Keven O'Connor - Houston TX, US
Steve Cortez - Katy TX, US

Assignee:

Baker Hughes Oilfield Operations LLC - Houston TX

International Classification:

E21B 43/10
E21B 47/16
E21B 47/09

Abstract:

A downhole tool for applying a force to a component in a borehole penetrating a subsurface formation includes an acoustic transducer configured to receive an acoustic signal. The tool also includes a spring having a spring force, a spring force retention device defining a perimeter having a gap and in mechanical communication with the component where the spring force retention device being configured to retain the spring force, and a gap member configured to be disposed in the gap. The tool further includes a force generator coupled to the gap member and in operable communication with the acoustic receiver and configured to operate in response to receiving the acoustic signal to withdraw the gap member from the gap to cause the spring force retention device to release the spring force thereby applying the spring force to the component.
