William G Quinn

US Patent:

20100087050, Apr 8, 2010

Filed:

Oct 2, 2009

Appl. No.:

12/587228

Inventors:

Eric A. Armour - Pennington NJ, US
William E. Quinn - Whitehouse Station NJ, US
Joshua Mangum - Basking Ridge NJ, US

Assignee:

Veeco Instruments Inc. - Plainview NY

International Classification:

H01L 21/363

US Classification:

438478, 118715, 118723 MP, 257E21462

Abstract:

Methods of depositing compound semiconductors onto substrates are disclosed, including directing gaseous reactants into a reaction chamber containing the substrates, selectively supplying energy to one of the gaseous reactants in order to impart sufficient energy to activate that reactant but insufficient to decompose the reactant, and then decomposing the reactant at the surface of the substrate in order to react with the other reactants. The preferred energy source is microwave or infrared radiation, and reactors for carrying out these methods are also disclosed.

US Patent:

20100310766, Dec 9, 2010

Filed:

Jun 7, 2009

Appl. No.:

12/479824

Inventors:

Eric A. Armour - Pennington NJ, US
William E. Quinn - Whitehouse Station NJ, US
Piero Sferlazzo - Marblehead MA, US

Assignee:

VEECO COMPOUND SEMICONDUCTOR, INC. - Somerset NJ

International Classification:

C23C 16/458
C23C 16/44

US Classification:

4272555, 118719

Abstract:

A roll-to-roll CVD system includes at least two rollers that transport a web through a deposition chamber during CVD processing. The deposition chamber defines a passage for the web to pass through while being transported by the at least two rollers. The deposition chamber includes a plurality of process chambers that are isolated by barriers which maintain separate process chemistry in each of the plurality of process chambers. Each of the plurality of process chambers includes a gas input port and a gas exhaust port, and a plurality of CVD gas sources. At least two of the plurality of CVD gas sources is coupled to the gas input port of each of the plurality of process chambers.

US Patent:

20100310769, Dec 9, 2010

Filed:

Jun 7, 2009

Appl. No.:

12/479834

Inventors:

Eric Armour - Pennington NJ, US
William E. Quinn - Whitehouse Station NJ, US
Piero Sferlazzo - Marblehead MA, US

Assignee:

Veeco Compound Semiconductor, Inc. - Somerset NJ

International Classification:

C23C 16/44

US Classification:

4272557, 118719

Abstract:

A continuous feed CVD system includes a wafer transport mechanism that transport a wafer through a deposition chamber during CVD processing. The deposition chamber defines a passage for the wafer to pass through while being transported by the wafer transport mechanism. The deposition chamber includes a plurality of process chambers that are isolated by barriers which maintain separate process chemistry in each of the plurality of process chambers. Each of the plurality of process chambers includes a gas input port and a gas exhaust port, and a plurality of CVD gas sources. At least two of the plurality of CVD gas sources are coupled to the gas input port of each of the plurality of process chambers.

US Patent:

20220333230, Oct 20, 2022

Filed:

Jun 30, 2022

Appl. No.:

17/854232

Inventors:

- Ewing NJ, US
Gregg KOTTAS - Ewing NJ, US
Gregory MCGRAW - Yardley PA, US
William E. QUINN - Whitehouse Station NJ, US

International Classification:

C23C 14/24
H01L 51/56
C23C 14/12

Abstract:

Embodiments of the disclosed subject matter provide an apparatus having a device with a micronozzle array disposed on a micro-fabricated fluidic die. The device may include a first gas distribution plate and a second opposing plate, where the micro-fabricated fluidic die is disposed between the first gas distribution plate and the second opposing plate, wherein the first gas distribution plate is irreversibly joined to the micronozzle array with a seal that is gas-tight, and where the first gas distribution plate includes a plurality of sealed flow paths. A manifold may be reversibly joined to the first gas distribution plate, where the micro-fabricated fluidic die and the first gas distribution plate and the second opposing plate are disposed between the manifold. A thermally conductive plate may have at least one window that provides a clearance fit for the device across a range of motion relative to the thermally conductive plate.

US Patent:

20230112871, Apr 13, 2023

Filed:

Dec 13, 2022

Appl. No.:

18/079976

Inventors:

- Ewing NJ, US
Gregory MCGRAW - Yardley PA, US
William E. QUINN - Whitehouse Station NJ, US
Gregg KOTTAS - Ewing NJ, US
Jason PAYNTER - Bristol PA, US
Julia J. BROWN - Yardley PA, US

International Classification:

H01L 51/00

Abstract:

Embodiments of the disclosed subject matter provide a device having a substrate, and a plurality of unit areas of an organic light emitting diode (OLED) display disposed on the substrate. The unit areas may be repeating, area-filling subdivisions on the substrate that each have an anode and a cathode. The organic film may be disposed over portions of the device other than the unit areas. The device may include at least one pixel having a plurality of sub-pixels disposed within each of the plurality of unit areas. The cathode of at least one pixel of each of the plurality of unit areas may be a common cathode.

US Patent:

20230040275, Feb 9, 2023

Filed:

Nov 19, 2020

Appl. No.:

17/777954

Inventors:

- Philadelphia PA, US
Brittney L. GURDA - Collegeville PA, US
Federico MINGOZZI - Philadelphia PA, US
Mustafa N. YAZICIOGLU - Broomall PA, US
William QUINN - Philadelphia PA, US

Assignee:

SPARK THERAPEUTICS, INC. - Philadelphia PA

International Classification:

C12N 15/62
A61K 39/35
A61K 39/00
C07K 14/705
C12N 15/86
A61K 48/00
A61P 37/06
A61K 31/436
C07K 14/47
C07K 14/005

Abstract:

Nucleic acids encoding fusion proteins that contain an unwanted antigen and a leader sequence for cell secretion are described. Also described are expression cassettes, vectors, cells, and cell lines containing the nucleic acids, as well as methods of using the nucleic acids to treat autoimmune, allergic and other diseases and disorders, such as multiple sclerosis.

US Patent:

20210351385, Nov 11, 2021

Filed:

Apr 7, 2021

Appl. No.:

17/224240

Inventors:

- Ewing NJ, US
Gregg KOTTAS - Ewing NJ, US
Gregory MCGRAW - Yardley PA, US
William E. QUINN - Whitehouse Station NJ, US

International Classification:

H01L 51/56
H01L 51/00
B41J 2/14

Abstract:

Embodiments of the disclosed subject matter provide an apparatus having a device with a micronozzle array disposed on a micro-fabricated fluidic die. The device may include a first gas distribution plate and a second opposing plate, where the micro-fabricated fluidic die is disposed between the first gas distribution plate and the second opposing plate, wherein the first gas distribution plate is irreversibly joined to the micronozzle array with a seal that is gas-tight, and where the first gas distribution plate includes a plurality of sealed flow paths. A manifold may be reversibly joined to the first gas distribution plate, where the micro-fabricated fluidic die and the first gas distribution plate and the second opposing plate are disposed between the manifold. A thermally conductive plate may have at least one window that provides a clearance fit for the device across a range of motion relative to the thermally conductive plate.

US Patent:

20210280785, Sep 9, 2021

Filed:

Oct 18, 2017

Appl. No.:

16/331615

Inventors:

- Ewing NJ, US
Gregory MCGRAW - Yardley PA, US
William E. QUINN - Whitehouse Station NJ, US

International Classification:

H01L 51/00
C23C 14/22
C23C 14/12
C23C 14/24

Abstract:

Devices and techniques are provided for depositing material on a substrate, such as for fabrication of OLEDs and layers used in OLEDs. A depositor block includes one or more delivery apertures, one or more exhaust apertures, and one or more confinement gas channels. Each delivery aperture is arranged such that it is between an exhaust aperture and a confinement gas channel, thereby improving deposition by reducing overspray of material.
