Arthur Dale Brummel

US Patent:

45518246, Nov 5, 1985

Filed:

Oct 14, 1982

Appl. No.:

6/434300

Inventors:

William Fehrenkamp - Houston TX
Arnold R. Pater - Houston TX
Arthur D. Brummel - Houston TX

Assignee:

AMF Incorporated - White Plains NY

International Classification:

G01V 116
G01V 122

US Classification:

367 76

Abstract:

A telemetry system adapter for connecting a recording station to a telemetry system having a plurality of data acquisition array terminals serially connected together by cables. The adapter may be used to connect the recording station to any array terminal in the telemetry system. At the array terminal to which it is desired to connect the recording station, the cable is disconnected from the array terminal and connected to one connector of the adapter. Another connector of the adapter is connected to the array terminal, and a third connector of the adapter is connected to the recording station. The connectors on the adapter will fit only a respective one of the array terminal connectors, the cable connector or the recording station connector, and therefore cannot be attached incorrectly. The adapter may include an attenuator for balancing data levels and reducing cross-talk interference.
