Austine Wood Comarow

US Patent:

8582063, Nov 12, 2013

Filed:

Jun 20, 2012

Appl. No.:

13/507316

Inventors:

Austine Wood Comarow - Las Vegas NV, US
Rufus Butker Seder - Arlington MA, US
David Comarow - Las Vegas NV, US

International Classification:

G02F 1/1333
G02F 1/1335
A63H 33/04

US Classification:

349122, 349 96, 446 85

Abstract:

Disclosed is a toy comprising polarizing filters and birefringent film cut into shapes used to make temporary colorful birefringent designs. The birefringent film (or, alternatively, the polarizing filter) is coated with non-water soluble, non-hygroscopic low-tack or ultra-low-tack adhesive so that changeable designs can be assembled on the polarizing filter and viewed through polarized spectacles or a polarizing filter. The polarizing filters are retained in rings that can be nested and rotated in relation to each other, or movably attached to each other with magnetic attachments. An embodiment is also disclosed which makes use of the polarized light emitted from certain LCD display devices so that they can be used as a work surface to make changeable birefringent designs. Such an implementation may also use applications executed by or stored on the device to provide design outlines.

US Patent:

8233099, Jul 31, 2012

Filed:

Apr 22, 2011

Appl. No.:

13/092796

Inventors:

Austine Wood Comarow - Las Vegas NV, US
David Comarow - Las Vegas NV, US
Rufus Butler Seder - Arlington MA, US

International Classification:

G02F 1/1335

US Classification:

349 5, 349 10

Abstract:

Disclosed is an apparatus and method for making temporary colorful birefringent displays. In its preferred embodiment, cellophane is laminated between self-adherent vinyl sheets with non-water soluble adhesive and desired shapes are cut therefrom. Plane polarizing filter is similarly laminated between sheets of self-adherent vinyl. One of the polarizer laminations is adhered to a gloss surface such as a window. Shapes cut from the cellophane-vinyl laminations are adhered to the polarizer lamination. Colors created by the polarized light passing through the birefringent cellophane laminations are viewed through a polarizing analyzer which can be a second lamination of polarizer between self-adherent vinyl sheets and placed over the completed design, or through analyzers held separately from the design such as polarized glasses or hand held viewers. Transmissive and reflective and transflective types are disclosed. A less-resilient but less expensive version using low-tack adhesive in place of surface-adherent vinyl is also described.
