Earl E Houcek

US Patent:

20100254556, Oct 7, 2010

Filed:

Apr 1, 2010

Appl. No.:

12/752262

Inventors:

Daniel Max Warren - Geneva IL, US
Thomas J. Jalava - Homer Glen IL, US
Brad Olson - Park Ridge IL, US
Michael J. Abry - Kildeer IL, US
Earl E. Houcek - Carol Stream IL, US
Mark F. Halla - Glen Ellyn IL, US
Charles B. King - Chicago IL, US

International Classification:

H04R 25/00

US Classification:

381328

Abstract:
